TX20D28VM2BAA KOE touch display panel lcd 8 inch 800(RGB)×480

Product Information Product Specifications
Model:
TX20D28VM2BAA
Brand:
KOE/HITACHI
Application:
Industrial
Size:
8"
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
1000
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.500 KG
Overview

TX20D28VM2BAA is KOE’s classic 8-inch wide WVGA industrial TFT module, designed for compact embedded control terminals, medical handheld equipment, factory HMI, transportation display and household intelligent appliance control screens.


Adopting TN liquid crystal with balanced 80° horizontal & down vertical viewing angle, it delivers stable color reproduction for single-front operation industrial scenarios, suitable for equipment operated by operators standing in front of the screen. Native 800×480 15:9 wide screen provides wider horizontal space to display multi-column parameter data, operation menus and real-time running curves without UI compression.

ParameterTechnical Specification
Full ModelTX20D28VM2BAA
ManufacturerKOE (Hitachi Group)
Diagonal Size8.0 inches
Native Resolution800(H) × 480(V) WVGA, 15:9, 116 PPI
LCD Technologya-Si TN TFT-LCD, Transmissive, Normally White
Pixel ArrangementRGB Vertical Stripe
Color Depth6-bit + FRC, 262K display colors, 60% NTSC gamut
Signal InterfaceSingle-channel 6-bit LVDS, 20Pin FPC connector, 3.3V logic voltage
Backlight SystemEdge-lit WLED array, onboard integrated LED driver IC, PWM dimming pin reserved
Rated Backlight Lifespan50,000 hours typical
Typical Brightness400 cd/m² industrial standard brightness
Typical Contrast Ratio600:1
Viewing Angle (CR≥10, L/R/U/D)80° / 80° / 60° / 80°, Optimal viewing: 6 o’clock front lower
Total Response Time (Tr+Td)35 ms typical
Refresh Rate60 Hz standard
Pixel Pitch0.2175 × 0.2175 mm
Active Display Area (AA)174.0 mm (W) × 104.4 mm (H)
Overall Outline Dimension189.0 mm (W) × 120.0 mm (H) × 8.0 mm thickness
Net Weight~165 g lightweight compact module
Surface PolarizerMatte anti-glare surface, standard scratch-resistant coating
Operating Temperature Range-20 ℃ ~ +70 ℃ wide industrial grade
Storage Temperature Range-30 ℃ ~ +80 ℃
Touch ConfigurationBare LCD without integrated touch; resistive/capacitive touch film optional optical bonding to form touch display panel
Compliance StandardRoHS Lead-Free Certified, mercury-free WLED backlight
Product StatusMass-production active industrial panel, A-grade new stock available for equipment assembly & maintenance replacement

Core Product Advantages

  1. -20℃ ~ +70℃ wide temperature tolerance: Works stably in cold storage, vehicle-mounted and general industrial cabinet environments

  2. Integrated WLED drive circuit: No separate external LED driver board required, lower assembly cost

  3. 400 cd/m² high brightness: Clear visibility under bright factory & medical indoor lighting

  4. Compact 8mm slim thickness & lightweight 165g, fits narrow embedded control cavity

  5. Standard single-channel LVDS interface, widely compatible with mature industrial control hardware

  6. Support custom touch bonding, can be made into integrated touch display panel

  7. Mercury-free long-life WLED backlight, eco-friendly with low power consumption

 Application Scenarios

  1. Compact factory automation HMI, small PLC production line monitoring control terminals

  2. Portable medical diagnostic instruments, handheld patient monitoring auxiliary screens

  3. Construction machinery, agricultural machinery vehicle-mounted industrial control displays

  4. Intelligent oven, commercial catering equipment, industrial testing instrument control panels

  5. Mini indoor self-service kiosks, logistics portable data recording terminals

  6. Custom touch integrated display panel after touch film optical bonding

  7. Replacement spare screen for KOE TX20D series 8" WVGA LVDS industrial TFT modules

English FAQ

Q1: Does TX20D28VM2BAA come with touch screen by default?

A1: No, the standard bare LCD panel has no touch sensor. The "touch display panel" in the title refers to finished assembly after additional optical bonding of resistive/capacitive touch film, which is customized product.

Q2: Does this panel need an external LED driver for backlight?

A2: No, WLED drive circuit is built into the LCM PCB; only standard DC power input is needed, PWM pin reserved for adjustable brightness dimming.

Q3: Can this panel connect HDMI/VGA signal sources directly?

A3: It only supports single-channel LVDS input; an extra LVDS to HDMI/VGA conversion driver board is required for analog/digital signal access.

Q4: What harsh temperature environments can this panel adapt to?

A4: Operating temperature -20~+70℃, suitable for unheated cold workshops, vehicle equipment and medium-temperature machinery cabinets; not recommended for long-term outdoor direct sunlight exposure.

Q5: What is the difference between TX20D28VM2BAA and TX20D200VM2BAB?

A5: Both are 8-inch 800×480 KOE panels; TX20D28VM2BAA is wide-temperature -20~70℃ version, TX20D200VM2BAB is standard indoor 0~50℃ cost version, mechanical dimensions interchangeable.




Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
TX20D28VM2BAA KOE  touch display panel lcd 8 inch 800(RGB)×480

TX20D28VM2BAA KOE touch display panel lcd 8 inch 800(RGB)×480

TX20D28VM2BAA

8"
TX20D203VM0BAA KOE 8 inch 800*480 tft lcd module

TX20D203VM0BAA KOE 8 inch 800*480 tft lcd module

TX20D203VM0BAA

8"
800(RGB)×480, WVGA, 15:9
550 cd/m² (Typ.)
700:1 (Typ.) (TM)
85/85/85/85 (Typ.)(CR≥10)
WLED, 70K hrs, With LED Driver
LVDS (1 ch, 8-bit), 20 pins Connector
a-Si TFT-LCD, LCM
TX20D28VM2BAA is a 8" Display screen Product from KOE/HITACHI.According to KOE/HITACHI's product specification sheet,TX20D28VM2BAA display has a resolution of , Contrast Ratio is ,Viewing Angle is ,Lamp Type is ,Signal Interface is ,Brightness is .Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of TX20D28VM2BAA after packaging is 1.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
