TS070OAAAD02-00 Tianma 7 inch a-Si TFT-LCD LCM 480(RGB)×234 76PPI

TS070OAAAD02-00 Tianma 7 inch a-Si TFT-LCD LCM 480(RGB)×234 76PPI

Name: TS070OAAAD02-00 Tianma 7 inch a-Si TFT-LCD LCM 480(RGB)×234 76PPI
Brand: TIANMA
Price: 105.0 USD

Price: $107.00

$105.00/ Price

Delivery:

Payment:

Calculate shipping price

Require:*

Product Model*	Target price	Qty *

Message

Your contact info:

Additional info:

Name: *

Mr.

Ms.

1. Quote with shipping freight?

Email : *

YES

Phone:

2. Which carrier do you perfert?

Company:

	Fedex		UPS		DHL
	TNT		other

Country:*

TS070OAAAD02-00 Tianma 7 inch a-Si TFT-LCD LCM 480(RGB)×234 76PPI

Product Information Product Specifications

Model:

TS070OAAAD02-00

Brand:

TIANMA

Application:

Industrial

Size:

Resolution:

480(RGB)×234 76PPI

Brightness:

200 cd/m² (Typ.)

Contrast Ratio:

400 : 1 (Typ.) (TM)

Viewing Angle:

65/65/45/65(Typ.)(CR≥10)

Lamp Type:

2S9PWLED, 20K hours, No Driver

Signal Interface:

TFTSpecificAnalogRGB,26pinsFPC

Panel Type:

a-Si TFT-LCD, LCM

Pixel Format:

RGB Vertical Stripe

Active Area:

154.08(W)×86.58(H) mm

Bezel Opening:

156.5(W)×89.00(H) mm

Outline size:

164.9 × 100× 6 (H×V×D)

Surface:

Antiglare

Response Time:

25 (Typ.)(Tr+Td) ms

Best View on:

12o'clock

Work Mode:

TN, Normally White, Transmissive

Display Colors:

Fullcolor50%NTSC

Weight:

158g(Typ.)

Frequency:

Touchscreen:

Without

Signal Type:

TFTSpecificAnalogRGB,26pinsFPC

Voltage Supply:

5.0/5.0/15.0/-10.0V(Typ.)(VCC/AVDD/VGH/VGL)

Ordering instructions

Quality:

test ok before ship it

RMA Policy:

RMA 6 month

Sample:

Paid Sample

Stock:

Stock Location:

China

Delivery:

WorldWide

Lead Time:

1-3 Days

Weight:

0.500 KG

Overview

Product display

TS070OAAAD02-00 is a 7" a-Si TFT-LCD, LCM Display screen Product from TIANMA.According to TIANMA's product specification sheet,TS070OAAAD02-00 display has a resolution of 480(RGB)×234 76PPI, Contrast Ratio is 400 : 1 (Typ.) (TM),Viewing Angle is 65/65/45/65(Typ.)(CR≥10),Lamp Type is 2S9PWLED, 20K hours, No Driver,Signal Interface is TFTSpecificAnalogRGB,26pinsFPC,Brightness is 200 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of TS070OAAAD02-00 after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
