n141c1-l04 innolux 14.1 inch 1440×900 lcd display screens
n141c1-l04 innolux 14.1 inch lcd display screens
N141C1-L04 is a cost-effective TN LCD display module launched by Innolux for the laptop market. It adopts mature and reliable a-Si TFT technology, which significantly reduces power consumption and cost while ensuring basic display effects. This module adopts an integrated LCM design, integrating the LCD panel, driver circuit, backlight system and inverter, making it easy to install and use.
This display module supports 16:10 widescreen display aspect ratio with RGB vertical stripe pixel arrangement, capable of clearly displaying text, charts and basic graphics. The integrated CCFL backlight system provides stable and uniform illumination with a typical lifespan of up to 15,000 hours. The 3.3V single power supply design simplifies system integration and reduces overall design complexity. The glossy 3H hard coating not only improves display effects but also enhances the screen's scratch resistance.
Original Innolux Quality: Manufactured by Innolux Corporation Taiwan, with a strict quality control system ensuring product reliability
High Resolution Display: 1440×900 WXGA+ resolution, 25% more display area than standard WXGA (1280×800)
High Contrast Performance: 700:1 typical contrast ratio, clear picture layers and vivid colors
Integrated LCM Structure: Integrated driver, backlight and inverter, plug-and-play, easy to install
Standard LVDS Interface: Dual-channel 6-bit LVDS 30-pin interface, widely compatible with mainstream laptops
Glossy Coating Design: 3H hard glossy coating, improves display effects and scratch resistance
n141c1-l04 innolux lcd display screens Detailed Parameters:
| Parameter Category | Detailed Parameters |
|---|---|
| Brand | Innolux (formerly Chi Mei Optoelectronics) |
| Model Number | N141C1-L04 |
| Panel Type | a-Si TFT-LCD, Liquid Crystal Display Module (LCM) |
| Panel Size | 14.1 inches (diagonal) |
| Resolution | 1440(RGB)×900 (WXGA+) |
| Pixel Density | 121 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Active Area | 303.48(W)×189.675(H) mm |
| Bezel Opening | 306.76(W)×193.0(H) mm |
| Outline Size | 319.5(W)×218(H)×5.5(D) mm |
| Surface Treatment | Glossy (Haze 0%), 3H Hard Coating, Reflectivity ≤2.0% |
| Panel Brightness | 230 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (Transmissive) |
| Viewing Angle | 45/45/20/45 (Typ.)(CR≥10) (L/R/U/D) |
| Best Viewing Angle | 6 o'clock |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 5/11 (Typ.)(Tr/Td) ms |
| Display Colors | 262K (6-bit) |
| Color Saturation | 45% NTSC (CIE1931) |
| Backlight Type | CCFL, 1 piece, integrated inverter |
| Backlight Life | 15000 hours (Typ.) |
| Operating Frequency | 60Hz |
| Signal Interface | LVDS (2 channels, 6-bit), 30-pin connector |
| Driving Voltage | 3.3V (Typ.) |
| Panel Weight | Approx. 480g (Typ.) |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
| Place of Origin | Taiwan, China |
| Quality Grade | Grade A Original Genuine |
n141c1-l04 innolux lcd display screens Applications:
Laptop Screen Replacement
Suitable for screen damage replacement of 14.1-inch 16:10 widescreen laptops from 2008 to 2012 that use the N141C1-L04 panel. Original quality, perfectly matches the drive system and mechanical structure of the original laptop, restoring the best display effect of the computer.
Used Laptop Refurbishment
Provides stable and reliable original panel supply for used laptop refurbishers. Replacing with a new N141C1-L04 screen can significantly improve the appearance and user experience of used laptops, increasing product prices and market competitiveness.
Education and Training Equipment
Suitable for repair and upgrade of old laptops in schools, training institutions and other places. Extend equipment service life and reduce education informatization costs.
FAQ:
Q1: Is N141C1-L04 a glossy screen or a matte screen?
A1: N141C1-L04 is a glossy screen with a surface treatment of Haze 0% glossy coating and 3H hardness scratch protection. Glossy screens have higher contrast and more vivid colors, but are prone to reflections in strong light environments.
Q2: Does N141C1-L04 include a backlight and inverter?
A2: Yes. N141C1-L04 is an integrated LCM liquid crystal display module, which not only includes the LCD panel and driver circuit, but also integrates the CCFL backlight tube and backlight inverter, no additional backlight driver circuit is required.
Q3: How do I confirm if my laptop is compatible with this screen?
A3: The most accurate method is to disassemble the laptop screen bezel and check the model label on the back of the original screen. If the original screen model is N141C1-L04, it is fully compatible. For screens of other models, you need to confirm whether the interface type (LVDS 30-pin), resolution (1440×900), screen size (14.1-inch 16:10) and thickness (5.5mm) match.
Q4: What is the quality grade of this screen? What quality guarantees are there?
A4: The N141C1-L04 screens we provide are all Grade A original genuine products, produced and tested in strict accordance with Innolux's quality standards. They have no bright spots, no dark spots, no lines, and no light leakage. We provide a 90-day quality warranty period. If there is a quality problem caused by non-human damage during the warranty period, we will replace or repair it for free.
