LCD display  TX18D211VM0BAA  7.0 inth   800*480   Industrial  screen     Automotive display       Rugged Industry     Outdoor High Brightness
LCD display TX18D211VM0BAA 7.0 inth 800*480 Industrial screen Automotive display Rugged Industry Outdoor High Brightness
Price: $200.00
$195.00/ piece
Add to cart
TX18D211VM0BAA
TX18D211VM0BAA
TX18D211VM0BAA
TX18D211VM0BAA
TX18D211VM0BAA
TX18D211VM0BAA

LCD display TX18D211VM0BAA 7.0 inth 800*480 Industrial screen Automotive display Rugged Industry Outdoor High Brightness

Price: $200.00
$195.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

LCD display TX18D211VM0BAA 7.0 inth 800*480 Industrial screen Automotive display Rugged Industry Outdoor High Brightness

Product Information Product Specifications
Model:
TX18D211VM0BAA
Brand:
KOE/HITACHI
Application:
Industrial
Size:
7"
Resolution:
800(RGB)×480, WVGA 133PPI
Brightness:
1200 cd/m² (Typ.)
Contrast Ratio:
1000:1 (Typ.) (TM)
Viewing Angle:
85/85/85/85 (Typ.)(CR≥10)
Lamp Type:
WLED , 50K hours , With LED Driver
Signal Interface:
LVDS (1 ch, 6-bit) , 20 pins Connector
Panel Type:
LTPS TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
85
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.000 KG
Overview

Product Introduction

The JDI TX18D211VM0BAA is a 7.0-inch industrial LCD module designed for demanding embedded and rugged applications. Its 800 × 480 WVGA transmissive display, 1200-nit brightness, wide operating temperature range, and 50,000-hour typical backlight lifetime support reliable readability in industrial and outdoor environments. The compact module features an IPS normally black display, LVDS interface, and low typical power consumption of 3.35 W.

Key Features

  • 0-inch LTPS TFT-LCD LCM with 800 (RGB) × 480 WVGA resolution and 133 PPI pixel density

  • High-brightness backlight rated at 1200 nits for improved visibility in demanding industrial environments

  • Wide operating temperature range from -40°C to 85°C and storage temperature range from -40°C to 90°C

  • IPS display mode with normally black transmissive configuration

  • Wide 85/85/85/85° viewing angles at a typical contrast ratio of 10:1 or higher

  • Single-channel 6-bit LVDS interface supporting 262K color depth

  • 96% sRGB coverage based on CIE 1931 measurements

  • Typical backlight lifetime of 50,000 hours

  • Low typical power consumption of 3.35 W with a 12.0V ± 1.0V power input

  • Compact outline dimensions of 167.7 × 109.5 mm and typical module weight of 219 g

  • 30 ms typical response time and 60 Hz refresh rate

Technical Specifications

Panel ModelTX18D211VM0BAA
Panel TypeLTPS TFT-LCD, LCM
Display Size7
Resolution800(RGB)×480 [WVGA] [133PPI]
Pixel Pitch0.1905×0.1905
Application FieldIndustrial
Operating Temperature-40 ~ 85 °C
Storage Temperature-40 ~ 90 °C
Brightness1200
Contrast Ratio1000 : 1 (Typ.) (Transmissive)
Response Time30 (Typ.)(Tr+Td) ms
Viewing Angle85/85/85/85 (Typ.)(CR≥10)
Color Depth262K (6-bit)
Color Temperature6638K
Display ModeIPS, Normally Black, Transmissive
Refresh Rate60Hz
sRGB Coverage96% coverage (CIE 1931)
Outline Dimension167.7(H)×109.5(V)
Active Area152.4(H)×91.44(V)
Weight219g (Typ.)
Voltage12.0±1.0V
Power Consumption3.35W (Typ.)
Backlight Lifetime50K (Typ.) hrs
InterfaceLVDS (1 ch, 6-bit)

Applications

  • Industrial control and operator-interface systems

  • Rugged industrial equipment and panel-mounted HMIs

  • Automotive display systems requiring a compact WVGA module

  • Outdoor industrial terminals and field-service equipment

  • Vehicle-mounted instrumentation and information displays

  • Test, measurement, and diagnostic equipment

  • Factory automation, process monitoring, and machine-control systems

Frequently Asked Questions

Q1: What display size and resolution does the TX18D211VM0BAA provide?

A: The module is a 7.0-inch LTPS TFT-LCD with an 800 (RGB) × 480 WVGA resolution, 133 PPI pixel density, and a 0.1905 × 0.1905 mm pixel pitch.

Q2: Is the TX18D211VM0BAA suitable for outdoor and rugged applications?

A: Yes. It combines a 1200-nit backlight, an operating temperature range of -40°C to 85°C, wide viewing angles, and a typical backlight lifetime of 50,000 hours for demanding industrial and outdoor environments.

Q3: What interface and color capability are provided?

A: The display uses a single-channel 6-bit LVDS interface and supports up to 262K colors, with 96% sRGB coverage based on CIE 1931 measurements.

Q4: What are the module's power specifications?

A: The TX18D211VM0BAA operates on 12.0V ± 1.0V and has a typical power consumption of 3.35 W.

Q5: What are the physical dimensions and weight?

A: The outline dimensions are 167.7 mm (H) × 109.5 mm (V), the active area is 152.4 mm (H) × 91.44 mm (V), and the typical module weight is 219 g.

Q6: What are the display's operating and storage temperature limits?

A: The operating temperature range is -40°C to 85°C, while the storage temperature range is -40°C to 90°C.
