G104XCE-L01 Innolux 10.4" a-Si TFT-LCD LCM 1024(RGB)×768 XGA 123PPI

Data sheets：
G104XCE-L01 Innolux 10.4" a-Si TFT-LCD LCM 1024(RGB)×768 XGA 123PPI.pdf
Product Information Product Specifications
Model:
G104XCE-L01
Brand:
INNOLUX
Application:
Desktop Monitor
Size:
10.4"
Resolution:
1024(RGB)×768, XGA 123PPI
Brightness:
500 cd/m² (Typ.)
Contrast Ratio:
1000:1 (Typ.) (TM)
Viewing Angle:
88/88/88/88 (Typ.)(CR≥10)
Lamp Type:
WLED , 50K hours , With LED Driver
Signal Interface:
LVDS (1 ch, 6/8-bit) , 30 pins Connector
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
20
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.000 KG
Overview

G104XCE-L01 Innolux 10.4" a-Si TFT-LCD  LCM 1024(RGB)×768  XGA  123PPI

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
G104XCE-L01 Innolux 10.4" a-Si TFT-LCD LCM 1024(RGB)×768 XGA 123PPI

G104XCE-L01 Innolux 10.4" a-Si TFT-LCD LCM 1024(RGB)×768 XGA 123PPI

G104XCE-L01

10.4"
1024(RGB)×768, XGA 123PPI
500 cd/m² (Typ.)
1000:1 (Typ.) (TM)
88/88/88/88 (Typ.)(CR≥10)
WLED , 50K hours , With LED Driver
LVDS (1 ch, 6/8-bit) , 30 pins Connector
a-Si TFT-LCD, LCM
G104STN01.5 10.4" panel lcd for AUO

G104STN01.5 10.4" panel lcd for AUO

G104STN01.5

10.4"
800(RGB)×600, SVGA 96PPI
400 cd/m² (Typ.)
700 : 1 (Typ.) (TM)
80/80/60/70 (Typ.)(CR≥10)
8S2P WLED , 50K hours , With LED Driver
LVDS (1 ch, 6/8-bit) , Connector 20 pins
a-Si TFT-LCD, LCM
LCD display G104XCE-LH1 10.4 inch 1024*768 Outdoor High Brightness Industrial screen

LCD display G104XCE-LH1 10.4 inch 1024*768 Outdoor High Brightness Industrial screen

G104XCE-LH1

10.4"
1024(RGB)×768, XGA 123PPI
1000 (Typ.)(cd/m²)
1000 : 1 (Typ.) (TM)
88/88/88/88 (Typ.)(CR≥10)
WLED , 50K hours , With LED Driver
LVDS (1 ch, 6/8-bit) , 30 pins Connector
a-Si TFT-LCD, LCM
G104XCE-LM1 10.4" lcd display panel for INNOLUX

G104XCE-LM1 10.4" lcd display panel for INNOLUX

G104XCE-LM1

10.1"
1024(RGB)×768, XGA 123PPI
350 cd/m² (Typ.)
1000:1 (Min.) (TM)
89/89/89/89 (Typ.)(CR≥10)
WLED , 50K hours , With LED Driver
LVDS (1 ch, 6/8-bit) , 30 pins Connector
a-Si TFT-LCD, LCM
G104XCE-L01 is a 10.4" a-Si TFT-LCD, LCM Display screen Product from INNOLUX.According to INNOLUX's product specification sheet,G104XCE-L01 display has a resolution of 1024(RGB)×768, XGA 123PPI, Contrast Ratio is 1000:1 (Typ.) (TM),Viewing Angle is 88/88/88/88 (Typ.)(CR≥10),Lamp Type is WLED , 50K hours , With LED Driver,Signal Interface is LVDS (1 ch, 6/8-bit) , 30 pins Connector,Brightness is 500 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Desktop Monitor and other products.The weight of G104XCE-L01 after packaging is 1.000KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
why choose us
Questions & Answers
Ask a Question >
All (5) uncategorised (5) Package (0) Delivery (0) Payment (0) After Sale (0)
Q:
In which fields is this 10.4-inch screen typically used?
A:
Leveraging its 10.4-inch size, 4:3 XGA resolution, and robust industrial characteristics, it is widely used in: Industrial HMI (Human-Machine Interface), medical equipment displays, POS systems, vehicle navigation/display terminals, test and measurement instruments, and various self-service kiosks and embedded display systems.
Q:
What do I need to drive this screen? Can it connect directly to HDMI?
A:
No, it cannot connect directly to HDMI. You need an LCD driver board. The function of this board is to convert the standard video signal (e.g., from HDMI, VGA, DP) from your computer or device into the LVDS signal and power required by this screen. You need to select a driver board that supports XGA resolution and the LVDS interface
Q:
What type of backlight does this screen use? What is its approximate lifespan?
A:
This module uses an LED backlight. LED backlights offer advantages such as long lifespan, low power consumption, and high brightness. Its typical backlight lifespan is usually > 50,000 hours (at normal temperature), meaning it is very durable under normal operating conditions.
Q:
What is its resolution? Is the aspect ratio 4:3?
A:
Yes, it has a resolution of 1024 (RGB) x 768, which is a standard XGA resolution. Its aspect ratio is the classic 4:3, making it very suitable for scenarios like industrial control and instrumentation that require displaying more content vertically.
Q:
What interface does this G104XCE-L01 display use?
A:
It uses a standard LVDS interface. Specifically, it employs 1 ch LVDS (1 clock pair, 3 data pairs) for signal transmission. This is an extremely common interface for industrial and medium-sized displays.
