Brand new universal display WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ
Brand new universal display WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ
Price: $95.00
$88.00/ piece
Add to cart
WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ
WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ
WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ
WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ

Brand new universal display WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ

Price: $95.00
$88.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

Brand new universal display WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ

Product Information Product Specifications
Model:
WG240128B-TMI-TZ# 240128B REV:K WG240128B-THF-VZ
Application:
Industrial
Size:
15"
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
1
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
2.000 KG
Overview
WG240128B series is a classic monochrome STN graphic LCD module manufactured by Winstar Display , resolution 240×128 dots, built-in RA6963/T6963C controller, widely used for industrial control equipment, medical instruments, CNC machine operation panels, PLC terminals, charging piles, and testing equipment.

Model Suffix Definition & Compatibility

  1. Base model: WG240128B REV:K (hardware revision K, consistent PCB layout)

  2. -TMI / -THF: Polarizer & backlight difference

    • TMI: STN Negative Blue (blue background, white text), white LED backlight

    • THF: STN Positive Yellow-Green (green background, black text), yellow-green LED backlight

  3. -TZ# / -VZ: Pin header length, mounting hole tolerance, fully mechanical interchangeable

Replacement Note: WG240128B-TMI-TZ# and WG240128B-THF-VZ share identical outline, mounting holes, 22Pin 8080 parallel interface, can cross replace only if host program supports screen color inversion.

2. Full Technical Specification Table


CategoryParameterStandard Value
Basic InfoFull Part No.WG240128B-TMI-TZ# / WG240128B-THF-VZ (240128B REV:K)

ManufacturerWinstar Display (Taiwan)

Dot Resolution240 (Horizontal) × 128 (Vertical) graphic dots

Diagonal Size4.8 inch
MechanicalOverall Module Dimension144.0(W) × 104.0(H) × 14.3(Max D) mm

Active View Area (AA)107.98(W) × 57.58(H) mm

Visible Display Area114.0 × 64.0 mm

Dot Pitch0.45 × 0.45 mm
LCD OpticalPanel TypeSTN Transmissive, TMI=Negative Blue / THF=Positive Yellow-Green

Drive Duty / Bias1/128 Duty, 1/16 Bias

Viewing Direction6 o’clock (bottom view, industrial standard)

Contrast RatioTMI ≥200:1; THF ≥150:1
ElectricalBuilt-in Controller ICRA6963 (compatible with T6963C driver program)

Interface22Pin 8-bit 8080 parallel MCU bus

Logic Supply VoltageDC 5V (4.7V ~ 5.3V)

LCD Driving VoltageOnboard negative voltage generation, no external booster needed
BacklightLight SourceSide-edge SMD LED backlight

Rated Lifespan50,000 hours to half brightness
EnvironmentalOperating Temp-20 ℃ ~ +70 ℃ (wide industrial grade)

Storage Temp-30 ℃ ~ +80 ℃

Humidity10% ~ 90% RH non-condensing
ComplianceCertificationRoHS, REACH industrial standard

3. 22Pin 8080 Parallel Interface Brief

Standard 22Pin horizontal pin header on PCB bottom, 5V logic level:
  1. Power pins: VSS(GND), VDD(+5V)

  2. 8-bit data bus: D0~D7

  3. Control signals: RS register select, WR write, RD read, RST hardware reset

  4. Backlight power pins: LED+, LED-

4. Core Feature Advantages

  1. Ultra-wide industrial temperature range (-20~70℃), stable operation for cold workshop / outdoor charging equipment

  2. Integrated RA6963 controller, support arbitrary graphics, Chinese/English fonts, curve waveform display

  3. Complete onboard circuit: negative voltage generation circuit integrated, only 5V single power input required

  4. Two mainstream display colors (blue negative / green positive) for different light environment matching

  5. Standard 22Pin parallel interface, compatible with most industrial PLC, single-chip MCU control programs

  6. Fixed 4-corner mounting hole layout, one-to-one replacement for all WG240128B REV series modules

  7. Low power monochrome STN design, long LED backlight service life for 24/7 unattended equipment

5. Typical Application Scenarios

  1. CNC injection molding, textile machinery HMI operation panel replacement

  2. Medical portable blood analyzers, ventilator parameter display screens

  3. New energy DC charging pile, energy storage cabinet monitoring display

  4. Industrial handheld fault detectors, environmental gas monitoring instruments

  5. Elevator control cabinet floor & fault code display terminal

  6. Laboratory test equipment, weighing instrument graphic data screen

6. Matching & Replacement Remarks

  1. Program adaptation: Blue negative (TMI) and green positive (THF) screens need display polarity inversion setting in host MCU program after replacement, otherwise image will be reversed.

  2. Power supply: Must supply stable 5V DC; do not input 3.3V directly, module cannot light up normally.

  3. Backlight: LED backlight without constant current IC, series current-limiting resistor recommended on host board to avoid over-current burnout.

  4. Stock status: New original Grade A Winstar modules in stock, full dot dead pixel inspection + 8-hour aging test before shipment, 90-day functional warranty.

7.  FAQ

Q1: Are TMI-TZ# and THF-VZ interchangeable?

A1: Mechanical size, pin definition and controller are identical, only display background color differs. You need to adjust the screen polarity register of the host driver program to use cross-replacement.

Q2: Does this module need external negative voltage circuit?

A2: No, negative voltage generating circuit is integrated on the PCB, only single 5V power supply is required.

Q3: What MCU interfaces support this screen?

A3: Standard 8-bit 8080 parallel bus, compatible with STM32, 51, PIC, PLC industrial main control boards.

Q4: What is the operating temperature limit?

A4: Industrial wide temperature: -20℃ ~ +70℃, suitable for unheated factory workshops and outdoor charging equipment.

Q5: Is the screen original Winstar brand?

A5: Available original Winstar new stock and fully tested compatible replacement screens, both pass full aging test before delivery.
