KOE TX14D10VM1BAA 5.7 Inch QVGA LCD Display Panel Replacement
KOE TX14D10VM1BAA 5.7 Inch QVGA LCD Display Panel Replacement
Price: $183.00
$180.00/ piece
Add to cart
KOE TX14D10VM1BAA 5.7 inch 320x240 QVGA Hitachi LCD panel front view
KOE TX14D10VM1BAA
KOE TX14D10VM1BAA 5.7 inch 320x240 QVGA Hitachi LCD panel front view
KOE TX14D10VM1BAA

KOE TX14D10VM1BAA 5.7 Inch QVGA LCD Display Panel Replacement

Price: $183.00
$180.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

KOE TX14D10VM1BAA 5.7 Inch QVGA LCD Display Panel Replacement

Product Information Product Specifications
Model:
TX14D10VM1BAA
Brand:
HITACHI
Application:
Industrial
Size:
5.7"
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
500
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
0.500 KG
Overview

Product Introduction

The TX14D10VM1BAA is a 5.7-inch a-Si TFT-LCD panel manufactured by Hitachi, designed for reliable performance in digital home appliances and industrial display applications. Featuring a VGA resolution of 640×480 pixels and a transmissive TN display mode, this LCM delivers consistent image quality with a typical brightness of 350 nits and a contrast ratio of 350:1. Engineered for wide operating temperature range from -20°C to 70°C, the TX14D10VM1BAA is built to withstand demanding environmental conditions. Its compact outline dimension of 131×102 mm and lightweight design at 160g make it suitable for space-constrained installations. The panel incorporates a WLED backlight with a typical lifetime of 40,000 hours and supports LVDS (1 ch, 6-bit) interface for seamless system integration.

Key Features

  • 7-inch a-Si TFT-LCD panel with VGA 640×480 RGB resolution

  • Typical brightness of 350 nits with 350:1 contrast ratio (Transmissive mode)

  • Wide operating temperature range: -20°C to 70°C

  • Storage temperature range: -30°C to 80°C

  • Viewing angles of 70/70/70/70 degrees (CR≥5)

  • Response time of 45 ms (Typ.) (Tr+Td)

  • Color depth supporting 262K colors (6-bit)

  • TN, Normally White display mode

  • 60Hz refresh rate

  • sRGB coverage of 74% (CIE 1931)

  • Compact outline dimensions: 131×102 mm

  • Active area: 115.2×86.4 mm

  • Lightweight design at 160g (Typ.)

  • Low power consumption of 1.479W (Typ.) at 12.0V

  • WLED backlight with 40,000 hours typical lifetime

  • LVDS (1 ch, 6-bit) interface for reliable signal transmission

Technical Specifications

Panel ModelTX14D10VM1BAA
Panel Typea-Si TFT-LCD, LCM
Display Size5.7
Resolution640(RGB)×480, VGA
Pixel Pitch0.060×0.180 mm
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
Brightness350
Contrast Ratio350:1 (Typ.) (Transmissive)
Response Time45 (Typ.)(Tr+Td) ms
Viewing Angle70/70/70/70 (Typ.)(CR≥5)
Color Depth262K (6-bit)
Color Temperature5598K
Display ModeTN, Normally White, Transmissive
Refresh Rate60Hz
sRGB Coverage74% coverage (CIE 1931)
Outline Dimension131(W)×102(H) mm
Active Area115.2(W)×86.4(H) mm
Weight160g (Typ.)
Voltage12.0V (Typ.)
Power Consumption1.479W (Typ.)
Backlight TypeWLED
Backlight Lifetime40K (Typ.) hrs
InterfaceLVDS (1 ch, 6-bit)

Applications

  • Digital home appliances

  • Industrial control equipment

  • Embedded display systems

  • Human-Machine Interface (HMI) panels

  • Medical instrumentation displays

  • Point-of-sale (POS) terminals

  • Test and measurement equipment

  • Portable industrial monitoring devices

Frequently Asked Questions

A: The TX14D10VM1BAA features a VGA resolution of 640(RGB)×480 pixels, providing standard display clarity suitable for industrial and home appliance applications.

Q1: What is the native resolution of the TX14D10VM1BAA LCD panel?

A: The TX14D10VM1BAA operates reliably within a temperature range of -20°C to 70°C, with a storage temperature range of -30°C to 80°C, making it suitable for diverse industrial environments.

Q2: What operating temperature range does this Hitachi display support?

A: This panel utilizes a WLED (White LED) backlight system with a typical lifetime of 40,000 hours, ensuring long-term operational reliability and reduced maintenance requirements.

Q3: What type of backlight is used in the TX14D10VM1BAA?

A: The TX14D10VM1BAA is equipped with an LVDS (1 channel, 6-bit) interface, providing stable and efficient signal transmission for industrial display integration.

Q4: What interface does the TX14D10VM1BAA support?

A: The TX14D10VM1BAA consumes approximately 1.479W (Typ.) at a typical voltage of 12.0V, offering energy-efficient operation suitable for continuous-use applications.

Q5: What is the typical power consumption of this LCD module?

A: The panel has outline dimensions of 131(W)×102(H) mm with an active display area of 115.2(W)×86.4(H) mm, and weighs approximately 160g, making it suitable for compact installations.

Q6: What are the physical dimensions and weight of the TX14D10VM1BAA?

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
KOE TX14D10VM1BAA 5.7 Inch QVGA LCD Display Panel Replacement

KOE TX14D10VM1BAA 5.7 Inch QVGA LCD Display Panel Replacement

TX14D10VM1BAA

5.7"
TX14D17VM1BPB  KOE 5.7 inch lcd panel

TX14D17VM1BPB KOE 5.7 inch lcd panel

TX14D17VM1BPB

5.7"
640*480
280
350:1
70/70/70/70
WLED
40 pins
a-Si TFT-LCD, LCM
TX14D10VM1BAA is a 5.7" Display screen Product from HITACHI.According to HITACHI's product specification sheet,TX14D10VM1BAA display has a resolution of , Contrast Ratio is ,Viewing Angle is ,Lamp Type is ,Signal Interface is ,Brightness is .Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of TX14D10VM1BAA after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
