NL2432HC22-45A 3.5 inch screen lcd module 240*320 lcd display panel For NEC

NL2432HC22-45A is a 3.5" a-Si TFT-LCD, LCM Display screen Product from NEC.According to NEC's product specification sheet,NL2432HC22-45A display has a resolution of ​240(RGB)×320, QVGA 113PPI, Contrast Ratio is 150 : 1 (Typ.) (TM),Viewing Angle is 35/35/35/35 (Typ.)(CR＞5),Lamp Type is 8S1P WLED , 12K hours , No Driver,Signal Interface is CMOS (1 ch, 6-bit) + SPI , 45 pins FPC,Brightness is 100 cd/m2 (Typ.).Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of NL2432HC22-45A after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
