Original Sharp LS105K5LX01 10.5" 1920×720  automotive LCD screen
Original Sharp LS105K5LX01 10.5" 1920×720 automotive LCD screen
Price: $135.00
$127.00/ piece
Add to cart
Original Sharp LS105K5LX01 10.5" 1920×720  automotive LCD screen
Original Sharp LS105K5LX01
Original Sharp LS105K5LX01
Original Sharp LS105K5LX01
Original Sharp LS105K5LX01

Original Sharp LS105K5LX01 10.5" 1920×720 automotive LCD screen

Price: $135.00
$127.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

Original Sharp LS105K5LX01 10.5" 1920×720 automotive LCD screen

Product Information Product Specifications
Model:
LS105K5LX01
Brand:
SHARP
Application:
Industrial
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
115
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.000 KG
Overview

Original Sharp LS105K5LX01 10.5" 1920×720  automotive LCD screen

The Sharp LS105K5LX01 is a high-reliability 10.5-inch automotive-grade a-Si TFT-LCD display module manufactured by Sharp Corporation, a global pioneer in display technology with over 100 years of innovation history. This panel is specifically designed for automotive infotainment and navigation systems, featuring a 1920×720 HD resolution with 201 PPI pixel density, delivering clear text and sharp graphics for in-vehicle multimedia and navigation applications. It incorporates Sharp's proprietary IPS (In-Plane Switching) technology, providing 85°/85°/85°/85° all-directional viewing angles (CR≥10) with consistent color reproduction and minimal brightness loss from any position, ensuring excellent visibility for both the driver and passengers.


With a typical brightness of 450 cd/m² and a 1000:1 contrast ratio, this display delivers vibrant colors and clear image quality even in bright sunlight conditions. It supports 16.7 million colors (8-bit) with 72% NTSC color gamut coverage, ensuring accurate color representation for maps, videos, and user interfaces. The panel has a glossy (anti-reflective) surface treatment with a scratch-resistant hard coating, enhancing durability and visibility in automotive environments.


The LS105K5LX01 uses a WLED backlight system with an integrated LED driver, offering a typical lifespan of 50,000 hours and low power consumption. It features an LVDS 2-channel interface with a 40-pin connector, providing stable and high-speed signal transmission suitable for automotive electronic systems. With a compact outline dimension of 260.0(W) × 100.0(H) × 8.5(D) mm, it is designed to fit perfectly into Ford's central control dashboard layouts.


Original Sharp LS105K5LX01 automotive LCD screen Highlights

Automotive Grade Reliability: Meets AEC-Q100 standards, designed to withstand extreme temperatures, vibrations, and harsh automotive environments

Sharp IPS Wide Viewing Technology: 85° all-directional viewing angles ensure consistent color and brightness for both driver and passengers

Sunlight Readable: 450 cd/m² high brightness provides excellent visibility even in direct sunlight conditions

Long Backlight Lifespan: 50,000-hour typical backlight life ensures reliable performance throughout the vehicle's lifespan

Ford Original Compatibility: Direct drop-in replacement for original displays in multiple Ford models, no modification required

Stable LVDS Interface: 2-channel LVDS interface provides reliable high-speed signal transmission for automotive systems

Scratch-Resistant Surface: Hard coating protects the screen from scratches and damage during daily use

Low Power Consumption: Energy-efficient WLED backlight system reduces vehicle battery load

Factory Tested: All panels undergo comprehensive functional, visual, and environmental testing before shipping


 Sharp LS105K5LX01automotive LCD screen Specification:


ParameterSpecification
ManufacturerSharp Corporation
Model NumberLS105K5LX01
Panel Typea-Si TFT-LCD, IPS Technology, Automotive Grade LCM
Diagonal Size10.5 inches
Resolution1920(RGB) × 720 (HD)
Pixel Density201 PPI
Pixel ArrangementRGB Vertical Stripe
Display Area243.84 (W) × 91.44 (H) mm
Outline Dimensions260.0 (W) × 100.0 (H) × 8.5 (D) mm (Typical)
Surface TreatmentGlossy (Anti-Reflective), Scratch-Resistant Hard Coating
Optical ModeIPS, Normally Black, Transmissive
Brightness450 cd/m² (Typical)
Contrast Ratio1000:1 (Typical, Transmission)
Viewing Angle85°/85°/85°/85° (Typical, CR≥10)
Color Depth8-bit (16.7 Million Colors)
Color Gamut72% NTSC (CIE1931)
Response Time25 ms (Typical, Tr+Td)
Refresh Rate60 Hz
Backlight TypeWLED (White LED), Integrated LED Driver
Backlight Lifespan50,000 hours (Typical)
Signal InterfaceLVDS, 2 Channels, 8-bit
Connector Type40-Pin Connector (Bottom Center Position)
Supply Voltage12.0V (Typical, Automotive Standard)
Power Consumption8.0W (Typical)
Touch FunctionNon-Touch (Compatible with Capacitive Touch Overlays)
Operating Temperature-30°C ~ 85°C (Automotive Grade)
Storage Temperature-40°C ~ 90°C
Vibration Resistance5G (49 m/s²)
CertificationsAEC-Q100, RoHS, REACH
Compatible Ford ModelsEscape (2020-2024), Explorer (2020-2024), Edge (2021-2024), F-150 (2021-2024)
Production StatusIn Production / Active Stock



Sharp LS105K5LX01automotive LCD screen Applications:

Ford Vehicle Central Control Displays: Direct replacement for Escape, Explorer, Edge, and F-150 infotainment and navigation screens

Automotive Infotainment Systems: Multimedia, audio, and video playback interfaces

In-Vehicle Navigation Systems: GPS and map display applications

Vehicle Status Monitoring: Fuel level, speed, and other vehicle information displays

Aftermarket Car Audio Systems: Upgrade displays for aftermarket head units

Commercial Vehicle Displays: Trucks, vans, and fleet vehicle information systems

Marine Displays: Boat and yacht navigation and control panels


FAQ:

Q1: Is the LS105K5LX01 compatible with my 2022 Ford Explorer?

A1: Yes, the LS105K5LX01 is a direct drop-in replacement for the original 10.5-inch display in 2020-2024 Ford Explorer models. It has identical dimensions, interface, and electrical specifications.

Q2: Does this screen include the touch digitizer?

A2: No, this is the LCD display panel only. The touch digitizer is a separate component that can be transferred from your original screen or purchased separately.


Q3: What is the difference between LS105K5LX01 and LS105K5LX02?

A3: They are functionally identical and fully interchangeable. The LS105K5LX02 is a minor revision with improved manufacturing processes and slightly better brightness consistency.

Q4: Can this display be used in other vehicle brands?

A4: While it is primarily designed for Ford vehicles, it can be used in other applications with a compatible LVDS interface and 12V power supply. However, mechanical fitment may require modification.

Q5: What warranty do you provide?

A5: We offer a 12-month warranty on all original Sharp LS105K5LX01 LCD panels. All screens are tested for dead pixels, backlight performance, and functionality before shipping.


Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
LS105K5LX01 is a a-Si TFT-LCD, LCM Display screen Product from SHARP.According to SHARP's product specification sheet,LS105K5LX01 display has a resolution of , Contrast Ratio is ,Viewing Angle is ,Lamp Type is ,Signal Interface is ,Brightness is .Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of LS105K5LX01 after packaging is 1.000KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
