The typical operating voltage for this panel is generally 3.3V or 5V; please refer to the official datasheet for exact specifications. As a 15-inch XGA LED panel, its power consumption is relatively low, typically ranging from 3W to 6W, depending on the backlight brightness setting.

It depends on your application. The LQ150X1LW73 is a "bare LCD panel" and does not include the circuitry to process common signals like HDMI or VGA. If your host board lacks LVDS output or if the signal format is incompatible, you will need to purchase a matching LCD controller/driver board that is compatible with the panel's parameters (size, resolution, interface, voltage) to convert your video signal (e.g., HDMI) into an LVDS signal the panel can understand.

This module features LED backlighting. Compared to older CCFL backlights, LED backlights offer a longer lifespan (typically 30,000 to 50,000+ hours), lower power consumption, a thinner profile, and are mercury-free, making them more environmentally friendly.

The LQ150X1LW73 typically uses an LVDS interface. This is a very common digital interface for industrial displays. Ease of connection depends on whether your controller or mainboard supports LVDS output. If it does, you usually only need to connect an LVDS cable and a power cable. Be sure to verify interface compatibility before purchasing.

This screen has a resolution of 1024 x 768 (XGA). With its moderate resolution and 15-inch size, it is well-suited for applications that require stable display rather than high pixel density, such as industrial control systems, medical instruments, POS terminals, replacement displays for older or specialized industrial PCs, and some test and measurement equipment.
