Name: LCD display T-55399D084J-FW-A-AAN 8.4 inch 640*480 Industrial screen
Brand: other PANEL
Price: 149.0 USD

LCD display T-55399D084J-FW-A-AAN 8.4 inch 640*480 Industrial screen

Price: $154.00

$149.00/ Price

Delivery:

Payment:

Calculate shipping price

LCD display T-55399D084J-FW-A-AAN 8.4 inch 640*480 Industrial screen

Data sheets：

LCD display T-55399D084J-FW-A-AAN 8.4 inch 640*480 Industrial screen.pdf

Product Information Product Specifications

Model:

T-55399D084J-FW-A-AAN

Brand:

other PANEL

Application:

Industrial

Size:

8.4"

Resolution:

640(RGB)×480, VGA 95PPI

Brightness:

480 cd/m² (Typ.)

Contrast Ratio:

600:1 (Typ.) (TM)

Viewing Angle:

80/80/80/60 (Typ.)(CR≥10)

Lamp Type:

2 pcs CCFL , 50K hours , Without Driver

Signal Interface:

CMOS (1 ch, 6-bit) , 31 pins Connector

Panel Type:

a-Si TFT-LCD, LCM

Frame Rate:

60Hz

Active Area:

170.88(W)×128.16(H) mm

Outline:

199.5(W)×149(H) ×12(D) mm

Storage Temp:

-30 ~ 80 °C

Operating Temp:

-30 ~ 80 °C

Support Color:

262K 41% NTSC

Ordering instructions

Quality:

test ok before ship it

RMA Policy:

RMA 6 month

Sample:

Paid Sample

Stock:

Stock Location:

China

Delivery:

WorldWide

Lead Time:

1-3 Days

Weight:

1.000 KG

Overview

LCD display T-55399D084J-FW-A-AAN 8.4 inch 640*480 Industrial screen

The T-55399D084J-FW-A-AAN is a high-reliability 8.4-inch industrial LCD display designed for demanding applications. With its 640×480 VGA resolution, this rugged display delivers clear and stable visualization for industrial control systems and human-machine interfaces. Engineered to perform in challenging environments, it features wide operating temperature range and robust construction that ensures long-term reliability in factory automation, process control, and specialized industrial settings. The display maintains consistent performance under continuous operation, making it suitable for integration into critical industrial equipment and automated systems. Its industrial-grade components and durable design provide a dependable viewing solution where operational stability is essential for seamless industrial operations and monitoring tasks.

Product Comparison

Model:

Size:

Resolution:

Brightness:

Contrast Ratio:

Viewing Angle:

Lamp Type:

Signal Interface:

Panel Type:

LCD display T-55399D084J-FW-A-AAN 8.4 inch 640*480 Industrial screen

T-55399D084J-FW-A-AAN

8.4"

640(RGB)×480, VGA 95PPI

480 cd/m² (Typ.)

600:1 (Typ.) (TM)

80/80/80/60 (Typ.)(CR≥10)

2 pcs CCFL , 50K hours , Without Driver

CMOS (1 ch, 6-bit) , 31 pins Connector

a-Si TFT-LCD, LCM

G104VTN01.0 AUO 10.4inch 640×480 LCD SCREEN

G104VTN01.0

10.4"

640(RGB)×480, VGA 76PPI

370 (Typ.)(cd/m²)

700 : 1 (Typ.) (TM)

80/80/60/80 (Typ.)(CR≥10)

WLED , 100K hours , With LED Driver

Parallel RGB (1 ch, 6-bit) , 40 pins Connector

a-Si TFT-LCD, LCM

Innolux G104S1-L01 10.4 inch lcd display screens

G104S1-L01

10.4"

800(RGB)×600, SVGA 96PPI

400 (Typ.)(cd/m²)

700 : 1 (Typ.) (TM)

80/80/70/70 (Typ.)(CR≥10)

WLED , 30K hours , With LED Driver

LVDS (1 ch, 6/8-bit) , 20 pins Connector

a-Si TFT-LCD, LCM

AUO G104SN03.5 10.4 inch Screen Display

G104SN03.5

10.4"

a-Si TFT-LCD, LCM

T-55399D084J-FW-A-AAN is a 8.4" a-Si TFT-LCD, LCM Display screen Product from other PANEL.According to other PANEL's product specification sheet,T-55399D084J-FW-A-AAN display has a resolution of 640(RGB)×480, VGA 95PPI, Contrast Ratio is 600:1 (Typ.) (TM),Viewing Angle is 80/80/80/60 (Typ.)(CR≥10),Lamp Type is 2 pcs CCFL , 50K hours , Without Driver,Signal Interface is CMOS (1 ch, 6-bit) , 31 pins Connector,Brightness is 480 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of T-55399D084J-FW-A-AAN after packaging is 1.000KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
