LCD display NL6448BC20-21D 6.5 inch 640*480 Industrial screen

Product Information Product Specifications
Model:
NL6448BC20-21D
Brand:
NEC
Application:
Industrial
Size:
6.5"
Resolution:
640(RGB)×480, VGA 122PPI
Brightness:
550 cd/m² (Typ.)
Contrast Ratio:
600 : 1 (Typ.) (TM)
Viewing Angle:
80/80/80/60 (Typ.)(CR≥10)
Lamp Type:
6 strings WLED , 40K hours , No Driver
Signal Interface:
LVDS (1 ch, 6/8-bit) , 20 pins Connector
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
79
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.000 KG
Overview

Product Introduction

The NLT NL6448BC20-21D is a 6.5-inch industrial a-Si TFT-LCD module designed for B2B embedded display applications. Its 640 × 480 VGA resolution, 550-nit brightness, 600:1 typical contrast ratio, and wide -20°C to 70°C operating-temperature range make it suitable for industrial equipment requiring reliable visual output. The transmissive, normally white TN display supports 60Hz refresh, 16.7M color depth, and an estimated 40,000-hour typical backlight lifetime.

Key Features

  • 5-inch a-Si TFT-LCD LCM with 640(RGB) × 480 VGA resolution

  • 550-nit brightness for industrial display visibility

  • 600:1 typical contrast ratio in transmissive mode

  • Wide operating temperature range from -20°C to 70°C

  • TN normally white transmissive display mode

  • 60Hz refresh rate

  • 7M color depth using 6-bit + Hi-FRC

  • 6/19ms typical response time for rise and fall

  • 40,000-hour typical backlight lifetime

  • Compact 153 × 118mm outline with a 132.48 × 99.36mm active area

Technical Specifications

Panel ModelNL6448BC20-21D
Panel Typea-Si TFT-LCD, LCM
Display Size6.5
Resolution640(RGB)×480, VGA
Pixel Pitch0.069×0.207 (H×V) mm
Application FieldIndustrial
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
Brightness550
Contrast Ratio600:1 (Typ.) (Transmissive)
Response Time6/19 (Typ.)(Tr/Td)
Color Depth262K/16.7M (6-bit / 6-bit + Hi-FRC)
Color Temperature6485K
Display ModeTN, Normally White, Transmissive
Refresh Rate60Hz
sRGB Coverage51% coverage (CIE 1931)
Outline Dimension153(H)×118(V) mm
Active Area132.48(H)×99.36(V) mm
Weight165/185g (Typ./Max.)
Voltage26.82/31.5V (Typ./Max.)
Backlight Lifetime40K (Typ.) hrs

Applications

  • Industrial HMI and operator control panels

  • Industrial automation and process-control equipment

  • Machine monitoring and control systems

  • Test and measurement instruments

  • Embedded industrial data visualization systems

Frequently Asked Questions

Q1: What is the display resolution of the NLT NL6448BC20-21D?

A: The module provides 640(RGB) × 480 resolution, equivalent to VGA.

Q2: What is the operating temperature range of the NL6448BC20-21D?

A: The specified operating temperature range is -20°C to 70°C. Its storage temperature range is -30°C to 80°C.

Q3: What type of display technology does the module use?

A: It uses an a-Si TFT-LCD LCM with a normally white, transmissive TN display mode.

Q4: What are the brightness and contrast specifications?

A: The specified brightness is 550, and the typical contrast ratio is 600:1 in transmissive mode.

Q5: What is the rated backlight lifetime?

A: The specified typical backlight lifetime is 40,000 hours.

Q6: What are the module dimensions and active display area?

A: The outline dimensions are 153mm high by 118mm wide. The active area measures 132.48mm horizontally by 99.36mm vertically.

Q7: How many colors can the display support?

A: The module supports up to 16.7M colors through 6-bit + Hi-FRC color depth.
