LCD display   KCG075VG2BE-G00    7.5 inth   600*480    Industrial  screen
LCD display KCG075VG2BE-G00 7.5 inth 600*480 Industrial screen
Price: $195.00
$190.00/ piece
Add to cart
KCG075VG2BE-G00
KCG075VG2BE-G00
KCG075VG2BE-G00
KCG075VG2BE-G00

LCD display KCG075VG2BE-G00 7.5 inth 600*480 Industrial screen

Price: $195.00
$190.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

LCD display KCG075VG2BE-G00 7.5 inth 600*480 Industrial screen

Product Information Product Specifications
Model:
KCG075VG2BE-G00
Brand:
KYOCERA
Application:
Industrial
Size:
7.5"
Resolution:
640(RGB)×480, VGA 107PPI
Brightness:
200 cd/m² (Typ.)
Contrast Ratio:
30:1 (Typ.) (TM)
Viewing Angle:
40/40/20/40 (Typ.)(CR≥2)
Lamp Type:
CCFL [2 pcs] , 58K hours , Optional
Signal Interface:
Parallel Data (1ch, 8-bit) , 20 pins Connector
Panel Type:
CSTN-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
150
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.000 KG
Overview

Product Introduction

The Kyocera KCG075VG2BE-G00 is a 7.5-inch industrial CSTN-LCD module designed for compact control, monitoring, and information-display systems. Its 640×480 VGA resolution, 200-nit brightness, 58,000-hour backlight lifetime, and operating temperature range of 0–60 °C make it suitable for industrial equipment requiring a durable, long-life display. The module uses a transmissive, normally black STN configuration and provides an 8-bit parallel data interface for straightforward integration.

Key Features

  • 5-inch CSTN-LCD module with 640 (RGB) × 480 VGA resolution

  • 107 PPI pixel density with a 0.237 × 0.237 mm pixel pitch

  • 200-nit brightness for standard industrial display applications

  • Transmissive, normally black STN display mode

  • 58,000-hour typical backlight lifetime for extended service intervals

  • Wide 0–60 °C operating temperature range

  • -20–60 °C storage temperature range

  • 8-bit parallel data interface

  • 75 Hz refresh rate with color display capability

  • Active area of 151.68 × 113.76 mm within a 184 × 139.8 mm outline

  • Typical contrast ratio of 30:1

  • Typical response time of 270/280 ms Tr/Td

  • Typical viewing angles of 40°/40°/20°/40°

  • 66% sRGB coverage based on CIE 1931

  • Color temperature of 6116 K

  • Lightweight construction at 280 g typical weight

Technical Specifications

Panel ModelKCG075VG2BE-G00
Panel TypeCSTN-LCD, LCM
Display Size7.5
Resolution640(RGB)×480 [VGA] [107PPI]
Pixel Pitch0.237×0.237
Application FieldIndustrial
Operating Temperature0 ~ 60 °C
Storage Temperature-20 ~ 60 °C
Brightness200
Contrast Ratio30 : 1 (Typ.) (Transmissive)
Response Time270/280 (Typ.)(Tr/Td) ms
Viewing Angle40/40/20/40 (Typ.)(CR≥2)
Color DepthColor
Color Temperature6116K
Display ModeSTN, Normally Black, Transmissive
Refresh Rate75Hz
sRGB Coverage66% coverage (CIE 1931)
Outline Dimension184(H)×139.8(V)
Active Area151.68(H)×113.76(V)
Weight280g (Typ.)
Voltage440V (Typ.)
Backlight Lifetime58K (Typ.) hrs
InterfaceParallel Data (1ch, 8-bit)

Applications

  • Industrial machinery control panels

  • Process and equipment monitoring systems

  • Factory automation interfaces

  • Instrumentation and test equipment

  • Industrial data acquisition terminals

  • Medical and laboratory instrument displays

  • Embedded operator interfaces

  • Status monitoring and diagnostic systems

Frequently Asked Questions

Q1: What display technology and resolution does the Kyocera KCG075VG2BE-G00 provide?

A: The module is a 7.5-inch CSTN-LCD with a 640 (RGB) × 480 VGA resolution and 107 PPI pixel density.

Q2: What interface is used for system integration?

A: The KCG075VG2BE-G00 uses a parallel data interface configured for 8-bit data transmission.

Q3: What is the typical backlight lifetime?

A: The backlight has a typical lifetime of 58,000 hours under the specified operating conditions.

Q4: What operating and storage temperature ranges are supported?

A: The operating temperature range is 0–60 °C, and the storage temperature range is -20–60 °C.

Q5: What is the active display area?

A: The active area measures 151.68 mm horizontally by 113.76 mm vertically. The overall outline dimensions are 184 × 139.8 mm.

Q6: Is the display suitable for industrial environments?

A: Yes. It is specified for industrial applications and includes a 0–60 °C operating range, 200-nit brightness, and a 58,000-hour typical backlight lifetime.
