Innolux  v400dj1-ks5  40 inch lcd panel
Innolux v400dj1-ks5 40 inch lcd panel
Price: $575.00
$570.00/ piece
Add to cart
Innolux  v400dj1-ks5  40 inch lcd panel
Innolux  v400dj1-ks5  40 inch lcd panel
Innolux  v400dj1-ks5  40 inch lcd panel
Innolux  v400dj1-ks5  40 inch lcd panel

Innolux v400dj1-ks5 40 inch lcd panel

Price: $575.00
$570.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

Innolux v400dj1-ks5 40 inch lcd panel

Product Information Product Specifications
Model:
v400dj1-ks5
Brand:
INNOLUX
Application:
Industrial
Resolution:
3840(RGB)×2160, UHD 111PPI
Brightness:
350 cd/m² (Typ.)
Contrast Ratio:
5000:1 (Typ.) (TM)
Viewing Angle:
89/89/89/89 (Typ.)(CR≥10)
Lamp Type:
WLED , 30K hours , With LED Driver
Signal Interface:
V-by-One 8 lane , 51 pins Connector
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
115
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
5.500 KG
Overview

Product Introduction

The Innolux V400DJ1-KS5 is a 40-inch a-Si TFT-LCD LCM panel designed for television applications. It features a 120Hz refresh rate, 1.07B color depth, 350 nit brightness, and a typical transmissive contrast ratio of 5000:1. The panel operates on 24.0±1.2V and uses an 8-lane V-by-One interface for integration into compatible display systems.

Key Features

  • 40-inch a-Si TFT-LCD LCM panel

  • Super MVA normally black transmissive display mode

  • 120Hz refresh rate

  • 350 nit brightness

  • 5000:1 typical transmissive contrast ratio

  • 07B color depth with 8-bit + Hi-FRC

  • 5 ms typical gray-to-gray response time

  • 8-lane V-by-One interface

  • 0±1.2V operating voltage

  • 6W typical and 43.2W maximum power consumption

  • 30,000-hour minimum backlight lifetime

  • Wide operating temperature range of 0°C to 50°C

  • Operating weight of 7.34 kg

Technical Specifications

Panel ModelV400DJ1-KS5
Panel Typea-Si TFT-LCD, LCM
Display Size40
Pixel Pitch0.0762×0.2247 mm
Application FieldTV Sets
Operating Temperature0 ~ 50 °C
Storage Temperature-20 ~ 60 °C
Brightness350
Contrast Ratio5000:1 (Typ.) (Transmissive)
Response Time8.5 (Typ.)(G to G) (ms)
Color Depth1.07B (8-bit + Hi-FRC)
Color Temperature9969K
Display ModeSuper MVA, Normally Black, Transmissive
Refresh Rate120Hz
Outline Dimension13.78/26.1 (Typ./Max.) mm
Active Area878.112×485.352 mm
Weight7.34Kgs (Typ.)
Voltage24.0±1.2V
Power Consumption37.6/43.2W (Typ./Max.)
Backlight Lifetime30K (Min.) hrs
InterfaceV-by-One 8 lanes

Applications

  • Television sets

  • 40-inch television display assemblies

  • TV manufacturing and integration projects

  • Compatible multi-panel display systems

Frequently Asked Questions

Q1: What display technology does the Innolux V400DJ1-KS5 use?

A: It uses a-Si TFT-LCD technology in an LCM configuration with a Super MVA, normally black, transmissive display mode.

Q2: What is the refresh rate of the V400DJ1-KS5 panel?

A: The panel has a 120Hz refresh rate.

Q3: What interface is provided on this 40-inch LCD panel?

A: The V400DJ1-KS5 uses an 8-lane V-by-One interface.

Q4: What are the brightness and contrast specifications?

A: The panel provides 350 nit brightness and a typical transmissive contrast ratio of 5000:1.

Q5: What power supply voltage is required?

A: The operating voltage is 24.0±1.2V. Typical power consumption is 37.6W, with a maximum of 43.2W.

Q6: What is the operating temperature range?

A: The specified operating temperature range is 0°C to 50°C. The storage temperature range is -20°C to 60°C.

Q7: What are the panel dimensions and active display area?

A: The outline dimensions are 13.78 mm typical and 26.1 mm maximum, while the active area measures 878.112 × 485.352 mm.

Q8: What color capability does the panel support?

A: The V400DJ1-KS5 supports 1.07B color depth using 8-bit + Hi-FRC, with a specified color temperature of 9969K.

v400dj1-ks5 is a a-Si TFT-LCD, LCM Display screen Product from INNOLUX.According to INNOLUX's product specification sheet,v400dj1-ks5 display has a resolution of 3840(RGB)×2160, UHD 111PPI, Contrast Ratio is 5000:1 (Typ.) (TM),Viewing Angle is 89/89/89/89 (Typ.)(CR≥10),Lamp Type is WLED , 30K hours , With LED Driver,Signal Interface is V-by-One 8 lane , 51 pins Connector,Brightness is 350 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of v400dj1-ks5 after packaging is 5.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
