HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P High-quality LCD Screen
HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P High-quality LCD Screen
Price: ₽25288.25
₽24899.20/ piece
Add to cart
HDM3224L-Z7RF
HDM3224L-Z7RF
HDM3224L-Z7RF
HDM3224L-Z7RF

HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P High-quality LCD Screen

Price: ₽25288.25
₽24899.20/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P High-quality LCD Screen

Product Information Product Specifications
Model:
HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P
Application:
Industrial
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
300
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
2.000 KG
Overview

HDM3224L-Z7RF, M032PGC1, LMCKBM032V36GKS and M032P belong to the same cross-compatible 5.7-inch monochrome FSTN industrial LCD module series with identical mechanical size, pin definition and driving parameters. This high-quality graphic LCD adopts mature FSTN liquid crystal technology with yellow-green LED backlight, delivering clear text, numerical data and simple industrial graphics under low-light workshop and cabin environments. Equipped with complete integrated PCB control board and universal 8-bit parallel TTL interface, it supports mainstream 6800/8080 microcontroller timing without extra conversion circuits, realizing plug-and-play replacement for aging original equipment screens. Designed with ultra-wide industrial temperature tolerance and reinforced anti-vibration housing, the module can run 24/7 continuously in marine vessels, injection molding machines, medical testing instruments and construction machinery cabins. Every unit passes full aging and optical inspection before shipment, providing stable long-term replacement solution for global industrial and marine equipment repair projects, fully compliant with RoHS environmental standards.

ParameterSpecification
Cross-Compatible Model ListHDM3224L-Z7RF, M032PGC1, LMCKBM032V36GKS, M032P
Diagonal Size5.7 inches
Native Resolution320 × 240 QVGA, 4:3 Aspect Ratio
Display TechnologyFSTN-LCD, Monochrome Positive Mode (Black text on yellow-green background)
Interface8-bit parallel TTL bus, compatible with 6800 / 8080 MCU timing, integrated PCB driver board
BacklightYG-LED backlight, typical lifespan ≥50,000 hours
Typical Brightness90 cd/m²
Typical Contrast Ratio22:1
Viewing Angle (L/R/U/D, CR≥5)50° / 50° / 35° / 35°
Pixel Pitch0.36 × 0.36 mm
Active Display Area115.2 mm (W) × 86.4 mm (H)
Overall Outline Dimension160.0 mm (W) × 109.0 mm (H) × 14.0 mm (D)
Surface TreatmentMatte anti-glare polarizer, reduce ambient light reflection
Logic Supply Voltage5.0 V DC standard input
Total Power Consumption≤ 2.6 W (Typical)
Operating Temperature Range-20 ℃ ~ +70 ℃
Storage Temperature Range-30 ℃ ~ +80 ℃
Vibration & Shock ResistanceIndustrial-grade anti-vibration structure for marine & heavy machinery
Compliance StandardRoHS Lead-Free Certified
Product StatusFully interchangeable cross-replacement series, new tested spot stock for equipment maintenance

 Application

Marine ship navigation monitoring displays

Injection molding & plastic machinery HMI control panels

Industrial PLC automation operation terminals

Medical auxiliary testing & diagnostic equipment

Construction machinery cabin monitoring screens

Old industrial equipment original screen cross-replacement

Portable industrial measuring & analytical instruments

 FAQ

Q1: Are HDM3224L-Z7RF, M032PGC1, LMCKBM032V36GKS and M032P mutually replaceable?
A1: Yes, all four models share identical outline dimension, pinout, interface and optical parameters, fully cross-compatible for direct replacement without hardware or software modification.
Q2: What resolution and display color does this series support?
A2: Native 320×240 QVGA monochrome display, black characters on yellow-green background, optimized for text and simple graphic industrial interface output.
Q3: What backlight type and lifespan does this LCD module use?
A3: Built-in yellow-green YG-LED backlight with typical service life over 50,000 hours, low power consumption and uniform illumination without external inverter.
Q4: What is the temperature working range of this industrial screen?
A4: Operating temperature from -20℃ to +70℃, storage temperature -30℃ ~ +80℃, suitable for cold workshop, ship cabin and heavy machinery harsh working environments.
Q5: Does this module come with integrated driver PCB?
A5: Yes, complete LCD module with integrated PCB driver board, standard TTL parallel interface header, directly matched with original equipment control motherboard.

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P High-quality LCD Screen

HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P High-quality LCD Screen

HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P

a-Si TFT-LCD, LCM
AV080HDM-N19 BOE 8 inch 1280*720 lcd display panel

AV080HDM-N19 BOE 8 inch 1280*720 lcd display panel

AV080HDM-N19

28"
1280(RGB)×720, WXGA, 16:9
800 cd/m² (Typ.)
900:1 (Typ.) (TM)
85/85/85/85 (Typ.)(CR≥10)
8S3P WLED, 30K hrs, Without Driver
LVDS (1 ch, 8-bit) + SPI, 30 pins FPC
a-Si TFT-LCD, LCM
AV090HDM-N13 BOE 9 inch 1280*720 tft lcd module

AV090HDM-N13 BOE 9 inch 1280*720 tft lcd module

AV090HDM-N13

9"
1280(RGB)×720, 16:9, WXGA
800 cd/m² (Typ.)
900:1 (Typ.) (TM)
80/80/80/80 (Typ.)(CR≥10)
9S3P WLED, 30K hrs, No DriverDriver
LVDS (1 ch, 8-bit), 60 pins FPC
a-Si TFT-LCD, LCM
HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P is a a-Si TFT-LCD, LCM Display screen Product from .According to 's product specification sheet,HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P display has a resolution of , Contrast Ratio is ,Viewing Angle is ,Lamp Type is ,Signal Interface is ,Brightness is .Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of HDM3224L-Z7RF M032PGC1 LMCKBM032V36GKS M032P after packaging is 2.000KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
