AUO G238HAN01.3 23.8" 1920x1080 FHD Commercial TFT LCD Module
AUO G238HAN01.3 23.8" 1920x1080 FHD Commercial TFT LCD Module
Price: $116.00
$113.00/ piece
Add to cart
AUO G238HAN01.3 23.8" 1920x1080 FHD Commercial TFT LCD Module
AUO G238HAN01.3 23.8 inch 1920x1080 FHD commercial LCD panel front view
Narrow bezel design of G238HAN01.3 23.8
Rear metal chassis and VESA mounting holes of AUO 23.8 inch LCM module
AUO G238HAN01.3 23.8 inch 1920x1080 FHD commercial LCD panel front view
Narrow bezel design of G238HAN01.3 23.8
Rear metal chassis and VESA mounting holes of AUO 23.8 inch LCM module

AUO G238HAN01.3 23.8" 1920x1080 FHD Commercial TFT LCD Module

Price: $116.00
$113.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

AUO G238HAN01.3 23.8" 1920x1080 FHD Commercial TFT LCD Module

Product Information Product Specifications
Model:
G238HAN01.3
Brand:
AUO
Application:
Industrial
Size:
23.8"
Resolution:
1920(RGB)×1080, FHD 92PPI
Brightness:
600 cd/m² (Typ.)
Contrast Ratio:
1000:1 (Typ.) (TM)
Viewing Angle:
89/89/89/89(Typ.)(CR≥10)
Lamp Type:
20S4PWLED, 50K hours, Without Driver
Signal Interface:
LVDS(2ch,8-bit),30pinsConnector
Panel Type:
a-Si TFT-LCD, LCM
Pixel Format:
RGB Vertical Stripe
Active Area:
527.04(W)×296.46(H) mm
Bezel Opening:
530.2(W)×299.6(H) mm
Outline size:
543(W)×317.4(H)×11.65(D) mm
Surface:
Antiglare,Hardcoating(3H)
Response Time:
-
Best View on:
Symmetry
Work Mode:
AHVA, Normally Black, Transmissive
Display Colors:
16.7M72%NTSC
Weight:
2.30Kgs(Typ.)
Frequency:
60Hz
Touchscreen:
20S4PWLED, 50K hours, Without Driver
Signal Type:
LVDS(2ch,8-bit),30pinsConnector
Voltage Supply:
5.0V(Typ.)
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
31
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
10.500 KG
Overview

Product Introduction

The AUO G238HAN01.3 is a premium 23.8-inch TFT LCD module engineered specifically for modern commercial displays and system integration. Delivering a crisp 1920x1080 (FHD) resolution with an optimal 92 PPI pixel density, this panel provides exceptional visual clarity for professional environments. As a complete LCM (Liquid Crystal Module), it features a highly sought-after narrow bezel design, maximizing the screen-to-body ratio for sleek desktop monitors, interactive self-service kiosks, and digital signage networks. The 23.8-inch form factor has become the industry standard for corporate workspaces and retail point-of-sale systems, offering the perfect balance between viewing area and desk footprint. At ZY LCD Shop, we supply genuine AUO commercial-grade panels directly to OEM manufacturers, system integrators, and repair facilities. Every G238HAN01.3 unit undergoes rigorous testing for color uniformity, backlight stability, and signal integrity. Elevate your display products today with our guaranteed authentic, factory-tested modules.

Core Product Features

  • Sleek Narrow Bezel Design: Ultra-thin borders maximize the active viewing area, making it ideal for modern edge-to-edge monitor designs and seamless multi-screen video wall configurations.

  • True Full HD Clarity: 1920x1080 resolution delivers razor-sharp text, detailed graphics, and smooth video playback essential for corporate presentations and digital advertising.

  • Complete LCM Assembly: Supplied as a fully integrated Liquid Crystal Module (including glass, backlight, and structural frame), streamlining the manufacturing process for OEM monitor builders.

  • Optimal 92 PPI Density: Provides the perfect pixel pitch for 23.8-inch desktop viewing distances, ensuring comfortable reading and precise image rendering without scaling issues.

  • Wide Viewing Angles: Advanced optical design ensures consistent color accuracy and contrast retention even when viewed from extreme off-axis positions in public spaces.

  • Commercial-Grade Reliability: Engineered for extended daily operation in retail stores, offices, and public kiosks, far exceeding the lifespan of standard consumer-grade panels.

Technical Specifications

ParameterSpecification Details
Part NumberG238HAN01.3
ManufacturerAUO (AU Optronics)
Diagonal Size23.8 Inch
Native Resolution1920(RGB) × 1080 (FHD)
Pixel Density92 PPI
Panel Technologya-Si TFT-LCD
Module TypeLCM (Liquid Crystal Module)
Aspect Ratio16:9 (Widescreen)
Signal InterfaceLVDS / eDP (Verify Pinout)
Backlight TypeWLED (White LED)
Bezel TypeNarrow Bezel / Frameless Design
Target ApplicationCommercial Monitors, Kiosks, Digital Signage

Typical Applications

  • OEM Desktop Computer Monitors & Corporate Office Displays

  • Interactive Self-Service Kiosks & Retail POS Terminals

  • Indoor Digital Signage & Menu Boards

  • Multi-Screen Video Walls & Control Room Dashboards

  • Medical Administrative Workstations & Clinic Reception Screens

Why Source from ZY LCD Shop?

  • Commercial Display Specialists: We maintain deep inventory of high-demand AUO 23.8-inch FHD panels required by OEM manufacturers and large-scale system integrators.

  • Strict Optical Verification: Every G238HAN01.3 is tested under magnification for dead pixels, Mura (clouding) effects, and backlight uniformity to guarantee pristine commercial quality.

  • Heavy-Duty Transit Packaging: Large-format 23.8-inch glass substrates require specialized protection. We use custom EPE foam, anti-static bags, and reinforced cartons to prevent transit damage.

  • Cross-Reference Engineering Support: Upgrading your monitor production line? Our team can help verify mechanical dimensions, mounting hole patterns, and signal interface compatibility.

FAQ (Frequently Asked Questions)

What makes the G238HAN01.3 suitable for modern commercial monitors?

The G238HAN01.3 features a narrow bezel design, which allows monitor manufacturers to create sleek, edge-to-edge displays that are highly demanded in modern office and retail environments. Additionally, its 23.8-inch FHD resolution is currently the industry standard for mainstream commercial desktop monitors.

Can I use this AUO panel to build a custom self-service kiosk?

Yes, absolutely. As a complete LCM (Liquid Crystal Module), it includes the necessary structural components and backlight system, making it an excellent choice for integrating into custom metal enclosures for self-service kiosks, ticketing machines, or interactive directories.

Where can I find the G238HAN01.3 datasheet and pinout definition?

We provide the official AUO PDF datasheet, including precise mechanical outlines, active area dimensions, and LVDS/eDP pin configurations, to verified buyers. Please contact our technical support department directly via email or phone to request your copy.

Is this panel just the raw glass, or does it include the backlight and frame?

The G238HAN01.3 is supplied as a complete LCM (Liquid Crystal Module). This means it includes the a-Si TFT glass cell, the integrated WLED backlight unit, and the structural metal bezel/frame, ensuring a straightforward installation process for system integrators.

How does the 92 PPI pixel density affect the viewing experience?

At 23.8 inches, 92 PPI (derived from the 1920x1080 resolution) provides the optimal pixel pitch for standard desktop viewing distances (typically 50-70 cm). It ensures that text remains sharp and UI elements are appropriately sized without requiring OS-level scaling, which is crucial for legacy commercial software.

Do you offer bulk pricing for OEM monitor manufacturers?

Absolutely. We actively support B2B wholesale orders for display manufacturers, system integrators, and commercial repair depots. Reach out to our sales department for custom tiered pricing based on your project's volume requirements.
