FG050722DSSWDG01   5.7"  lcd   display  panel  for Data Image
FG050722DSSWDG01 5.7" lcd display panel for Data Image
Price: $65.00
$62.00/ piece
Add to cart
FG050722DSSWDG01   5.7"  lcd   display  panel  for Data Image
FG050722DSSWDG01   5.7
Data Image FG050722DSSWDG01   5.7
FG050722DSSWDG01   5.7
Data Image FG050722DSSWDG01   5.7

FG050722DSSWDG01 5.7" lcd display panel for Data Image

Price: $65.00
$62.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

FG050722DSSWDG01 5.7" lcd display panel for Data Image

Product Information Product Specifications
Model:
FG050722DSSWDG01
Application:
Industrial
Size:
5.7"
Resolution:
640(RGB)×480, VGA 141PPI
Brightness:
400 cd/m² (Typ.)
Contrast Ratio:
300:1 (Typ.) (TM)
Viewing Angle:
70/70/60/40 (Typ.)(CR≥10)
Lamp Type:
WLED , 50K hours , With LED Driver
Signal Interface:
LVDS (1 ch, 6-bit) , 20 pins Connector
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
115
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
0.500 KG
Overview

Product Introduction

The Data FG050722DSSWDG01 is a 5.7-inch industrial a-Si TFT-LCD display panel designed for compact yet demanding industrial equipment. This transmissive, normally white LCM delivers VGA resolution, 400-nit brightness, a 300:1 typical contrast ratio, and 262K color depth across a 115.2 × 86.4 mm active area. It operates reliably from -20°C to 70°C and includes a 50,000-hour typical backlight for applications requiring clear visual output and dependable operation.

Key Features

  • 7-inch a-Si TFT-LCD LCM with a 640 × 480 VGA resolution

  • 400-nit brightness for clear industrial display performance

  • Transmissive, normally white display mode

  • 300:1 typical contrast ratio

  • 262K color depth with 6-bit color representation

  • 60Hz refresh rate and typical 15/35 ms response time

  • Wide operating temperature range of -20°C to 70°C

  • Storage temperature range of -30°C to 80°C

  • 50,000-hour typical backlight lifetime

  • Compact 129 × 98 mm outline with a 115.2 × 86.4 mm active area

  • Low typical power requirement of 5.0 ± 0.5V

  • 67% sRGB coverage based on CIE 1931

  • Lightweight construction at 110g typical weight

Technical Specifications

Panel ModelFG050722DSSWDG01
Panel Typea-Si TFT-LCD, LCM
Display Size5.7
Resolution640(RGB)×480, VGA
Pixel Pitch0.060×0.180 (H×V) mm
Application FieldIndustrial
Operating Temperature-20 ~ 70 °C
Storage Temperature-30 ~ 80 °C
Brightness400
Contrast Ratio300:1 (Typ.) (Transmissive)
Response Time15/35 (Typ.)(Tr/Td)
Color Depth262K (6-bit)
Color Temperature6796K
Display ModeTN, Normally White, Transmissive
Refresh Rate60Hz
sRGB Coverage67% coverage (CIE 1931)
Outline Dimension129(H)×98(V) mm
Active Area115.2(H)×86.4(V) mm
Weight110g (Typ.)
Voltage5.0±0.5V
Backlight Lifetime50K (Typ.) hrs

Applications

  • Industrial equipment interfaces and operator control panels

  • Factory automation and process monitoring systems

  • Industrial instrumentation and data acquisition devices

  • Machine vision and inspection systems

  • Material handling and warehouse equipment

  • Test and measurement equipment

  • Embedded industrial computing systems

Frequently Asked Questions

Q1: What display technology does the FG050722DSSWDG01 use?

A: It is a 5.7-inch a-Si TFT-LCD LCM using a transmissive, normally white display mode.

Q2: What is the native resolution and refresh rate?

A: The panel provides a native VGA resolution of 640 × 480 pixels with a 60Hz refresh rate.

Q3: What are the brightness and contrast specifications?

A: The display features 400-nit brightness and a 300:1 typical contrast ratio.

Q4: What operating temperature range is supported?

A: The specified operating temperature range is -20°C to 70°C. The storage temperature range is -30°C to 80°C.

Q5: How long is the backlight rated to operate?

A: The backlight has a typical lifetime of 50,000 hours.

Q6: What are the panel dimensions and viewing area?

A: The outline dimensions are 129 × 98 mm, and the active area measures 115.2 × 86.4 mm.

Q7: What power supply voltage does the panel require?

A: The specified operating voltage is 5.0 ± 0.5V.

Q8: What color capability is provided?

A: The panel supports 262K colors using 6-bit color depth, with 67% sRGB coverage based on CIE 1931.

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
FG050722DSSWDG01   5.7"  lcd   display  panel  for Data Image

FG050722DSSWDG01 5.7" lcd display panel for Data Image

FG050722DSSWDG01

5.7"
640(RGB)×480, VGA 141PPI
400 cd/m² (Typ.)
300:1 (Typ.) (TM)
70/70/60/40 (Typ.)(CR≥10)
WLED , 50K hours , With LED Driver
LVDS (1 ch, 6-bit) , 20 pins Connector
a-Si TFT-LCD, LCM
FG050720DSSWDGL4 5.7 inch lcd controller board screen

FG050720DSSWDGL4 5.7 inch lcd controller board screen

FG050720DSSWDGL4

5.7"
640(RGB)×480, VGA 141PPI
900 cd/m² (Typ.)
300:1 (Typ.) (TM)
70/70/60/40 (Typ.)(CR≥10)
WLED , 50K hours , With LED Driver
Parallel RGB (1 ch, 6-bit) , 40 pins Connector
a-Si TFT-LCD, LCM
FG050722DUSWMG07   Data Image   5.7  LCD

FG050722DUSWMG07 Data Image 5.7 LCD

FG050722DUSWMG07 Data Image 5.7 LCD

5.7"
640(RGB)×480, VGA 141PPI
500 cd/m² (Typ.)
300:1 (Typ.) (TM)
80/80/80/80 (Typ.)(CR≥10)
WLED , 30K hours , With LED Driver
LVDS (1 ch, 6-bit) , 20 pins Connector
a-Si TFT-LCD, LCM
FG050701DSSWBGL2 Original TFT LCD display touch screen 5.7 inch

FG050701DSSWBGL2 Original TFT LCD display touch screen 5.7 inch

FG050701DSSWBGL2

5.7"
320(RGB)×240, QVGA 70PPI
490 cd/m² (Typ.)
350:1 (Typ.) (TM)
70/70/50/70 (Typ.)(CR≥10)
WLED [3S7P] , 50K hours , With LED Driver
Parallel RGB (1 ch, 6-bit) , 33 pins Connector
a-Si TFT-LCD, LCM
