ed090na-01d is a 9" a-Si TFT-LCD, Assembly Display screen Product from INNOLUX.According to INNOLUX's product specification sheet,ed090na-01d display has a resolution of 1280(RGB)×800, WXGA 167PPI, Contrast Ratio is 700 : 1 (Typ.) (TM),Viewing Angle is 70/70/70/50 (Typ.)(CR≥10),Lamp Type is 3S12P WLED , 20K hours , No Driver,Signal Interface is LVDS (1 ch, 6/8-bit) , Connector 51 pins,Brightness is 200 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Tablet and other products.The weight of ed090na-01d after packaging is 1.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
