B140HAN07.1 AUO 14"1920×1080 lcd display module
The AUO B140HAN07.1 is a high-performance 14.0-inch a-Si TFT-LCD display module manufactured by AU Optronics, a global leading provider of display solutions. This panel features a Full HD (1920×1080) resolution with 157 PPI pixel density, delivering clear text and sharp graphics for everyday office work, web browsing, and multimedia consumption. It incorporates AUO's proprietary AHVA (Advanced Hyper-Viewing Angle) technology, providing 85°/85°/85°/85° all-directional viewing angles (CR≥10) with consistent color reproduction and minimal brightness loss from any position.
With a typical brightness of 250 cd/m² and a 700:1 contrast ratio, this display delivers adequate image quality for indoor environments. It supports 16.2 million colors (6-bit + Hi-FRC) with 45% NTSC color gamut coverage, making it suitable for general-purpose applications. The panel has a matte (anti-glare) surface treatment with a 3H hard coating, reducing reflections and eye strain during extended use.
The B140HAN07.1 uses a WLED backlight system with an integrated LED driver, offering a typical lifespan of 15,000 hours and low power consumption. It features an eDP 1.3 interface with 2 lanes and a 30-pin connector (bottom right position), providing stable signal transmission and broad compatibility with modern business laptops. With a slim profile of only 5.25mm, it is ideal for thin and light business notebooks.
B140HAN07.1 AUO lcd display module Highlights:
AUO AHVA Wide Viewing Technology: 85° all-directional viewing angles ensure consistent color and brightness from any position, eliminating color shift and distortion
Clear FHD Display: 1920×1080 resolution with 157 PPI delivers sharp text and graphics for office productivity and multimedia use
Anti-Glare Matte Surface: Reduces reflections and eye strain, ideal for long hours of office work and study
Low Power Consumption: WLED backlight system offers energy efficiency and extends battery life
Stable eDP Interface: 2-channel eDP 1.3 interface provides reliable signal transmission and broad compatibility
Integrated LED Driver: Simplifies system design and reduces component count
Long Backlight Lifespan: 15,000 hours of typical backlight life ensures reliable long-term performance
Broad Compatibility: Direct replacement for multiple popular Dell Latitude business laptop models
Factory Tested: All panels undergo comprehensive functional and visual testing before shipping
B140HAN07.1 AUO lcd display module Specification:
| Parameter | Specification |
|---|---|
| Manufacturer | AU Optronics (AUO) |
| Model Number | B140HAN07.1 (Alias: AUO8291) |
| Panel Type | a-Si TFT-LCD, AHVA Technology, LCM |
| Diagonal Size | 14.0 inches |
| Resolution | 1920(RGB) × 1080 (FHD / 1080p) |
| Pixel Density | 157 PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Area | 309.37 (W) × 174.02 (H) mm |
| Outline Dimensions | 315.87 (W) × 187.68 (H) × 5.25 (D) mm |
| Surface Treatment | Matte (Anti-Glare), Hard Coating (3H) |
| Optical Mode | AHVA, Normally Black, Transmissive |
| Brightness | 250 cd/m² (Typical) |
| Contrast Ratio | 700:1 (Typical, Transmission) |
| Viewing Angle | 85°/85°/85°/85° (Typical, CR≥10) |
| Color Depth | 6-bit + Hi-FRC (16.2 Million Colors) |
| Color Gamut | 45% NTSC (CIE1931) |
| Response Time | 25 ms (Typical, Tr+Td) |
| Refresh Rate | 60 Hz |
| Backlight Type | WLED (White LED), Integrated LED Driver |
| Backlight Lifespan | 15,000 hours (Typical) |
| Signal Interface | eDP 1.3, 2 Lanes |
| Connector Type | 30-Pin Connector (Bottom Right Position) |
| Supply Voltage | 3.3V (Typical) |
| Touch Function | No Touch Screen |
| Operating Temperature | 0°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C |
| RoHS Compliance | Yes |
| Compatible Dell Part Numbers | D5MVF, CN-0D5MVF, RH0D1, CN-0RH0D1 |
| Production Status | In Production |
B140HAN07.1 AUO lcd display module Applications:
Laptop Replacement Screens: Direct replacement for Dell Latitude 5400, 5410, 5420, and 3420 series business laptops
Business Laptops: Standard display solution for entry-level and mid-range business notebooks
Educational Devices: Student laptops and classroom computers
Industrial Terminals: Basic human-machine interfaces (HMIs) and control panels
All-in-One PCs: Compact desktop computers with integrated displays
Portable Monitors: Low-cost external displays for laptops and mobile devices
POS Systems: Point-of-sale terminals and cash registers
FAQ:
Q1: Is the B140HAN07.1 compatible with my Dell Latitude 5420?
A1: Yes, the B140HAN07.1 is a direct replacement for the original display in Dell Latitude 5400, 5410, 5420, and 3420 series laptops. It is compatible with Dell part numbers D5MVF and RH0D1.
Q2: What is the difference between B140HAN07.1 and B140HAN07.H?
A2: The main difference is the color gamut. B140HAN07.1 has 45% NTSC coverage, while B140HAN07.H has 72% NTSC coverage. They are not interchangeable due to different electrical specifications.
Q3: Does this screen have a glossy or matte finish?
A3: The B140HAN07.1 has a matte (anti-glare) surface finish with a 3H hard coating to reduce reflections.
Q4: What is the dead pixel policy?
A4: All our screens are tested before shipping. We follow the ISO 13406-2 standard for dead pixels.
Q5: What warranty do you provide?
A5: We offer a 6-month warranty on all original AUO B140HAN07.1 LCD panels. All screens are tested for dead pixels and functionality before shipping.
