B125HAK01.0 12.5" FHD AHVA LCD Panel AUO Laptop Display Screen
B125HAK01.0 12.5" FHD AHVA LCD Panel AUO Laptop Display Screen
Price: $90.00
$85.00/ piece
Add to cart
B125HAK01.0 12.5
B125HAK01.0 12.5
B125HAK01.0 12.5
B125HAK01.0 12.5

B125HAK01.0 12.5" FHD AHVA LCD Panel AUO Laptop Display Screen

Price: $90.00
$85.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

B125HAK01.0 12.5" FHD AHVA LCD Panel AUO Laptop Display Screen

Product Information Product Specifications
Model:
B125HAK01.0
Brand:
AUO
Application:
Tablet
Size:
12.5"
Resolution:
1920(RGB)×1080, FHD 176PPI
Brightness:
300 cd/m² (Typ.)
Contrast Ratio:
800:1 (Typ.) (TM)
Viewing Angle:
Symmetry
Lamp Type:
a-Si TFT-LCD, LCM
Signal Interface:
eDP (2 Lanes) , eDP1.2 , 40 pins Connector
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
116
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
1.500 KG
Overview

AUO B125HAK01.0 12.5-Inch Full HD AHVA TFT-LCD Display Module


The AUO B125HAK01.0 is a premium 12.5-inch Full HD TFT-LCD panel designed for laptops, embedded computing systems, industrial terminals, and OEM display applications. Featuring a 1920 × 1080 Full HD resolution, AHVA wide-viewing-angle technology, and an integrated WLED backlight system, this display delivers sharp image quality, consistent color performance, and reliable long-term operation.

Manufactured by AU Optronics, the B125HAK01.0 combines a slim-profile design with low power consumption and wide viewing angles, making it an ideal solution for laptop screen replacement, embedded display integration, and professional equipment upgrades.


Key Features

12.5-inch Full HD TFT-LCD panel

Native resolution: 1920 × 1080 (FHD)

AHVA wide viewing angle technology

300 cd/m² typical brightness

800:1 contrast ratio

eDP 1.2 interface (40-pin, 2 lanes)

WLED backlight with integrated driver

Matte anti-glare surface

Slim 3.0 mm profile design

Suitable for laptop and embedded display applications


Technical Specifications

SpecificationDetails
ModelB125HAK01.0
ManufacturerAUO
Display Size12.5 Inch
Resolution1920 × 1080 (FHD)
Display Technologya-Si TFT-LCD
Display ModeAHVA, Normally Black, Transmissive
Brightness300 cd/m² (Typ.)
Contrast Ratio800:1 (Typ.)
Viewing Angle85/85/85/85
Display Colors16.7M Colors
Color Gamut73% NTSC
Active Area276.48 × 155.52 mm
Outline Size282.4 × 179.32 × 3.0 mm
InterfaceeDP 1.2, 40 Pins, 2 Lanes
BacklightWLED, 12,000 Hours
Refresh Rate60Hz
Surface TreatmentMatte (Anti-Glare)
Input Voltage3.3V
Operating Temperature0°C to +50°C
Storage Temperature-20°C to +60°C


Typical Applications

The B125HAK01.0 LCD panel is widely used in:

Laptop display replacement

Industrial embedded computers

Portable medical equipment

HMI control systems

Test and measurement devices

OEM notebook manufacturing

Educational devices

Commercial computing terminals

Portable industrial workstations

Embedded display projects


Why Choose the B125HAK01.0?

The B125HAK01.0 combines Full HD resolution, AHVA wide viewing angles, and a slim lightweight design, providing an excellent balance of image quality and energy efficiency. Its eDP interface and mature AUO technology make it a dependable choice for OEM manufacturers, repair professionals, and system integrators seeking a reliable 12.5-inch display solution.


Quality Assurance & Supply Support

Original AUO LCD panel

Fully tested before shipment

Secure anti-static packaging

Global shipping available

OEM and bulk order support

Technical integration assistance

Replacement sourcing support


FAQ Section

Is the B125HAK01.0 an IPS display?

The panel uses AHVA technology, which belongs to the IPS-family display technologies and provides wide viewing angles and improved color consistency.

What resolution does the B125HAK01.0 support?

The display provides a native resolution of 1920 × 1080 pixels (Full HD).

What interface does the B125HAK01.0 use?

The panel uses a 40-pin eDP interface with 2 lanes, commonly found in modern laptop and embedded display systems.

Is this panel suitable for laptop screen replacement?

Yes. The B125HAK01.0 is commonly used for compatible 12.5-inch Full HD laptop display replacement projects. Compatibility should be verified before installation.

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
B125HAK01.0 12.5" FHD AHVA LCD Panel AUO Laptop Display Screen

B125HAK01.0 12.5" FHD AHVA LCD Panel AUO Laptop Display Screen

B125HAK01.0

12.5"
1920(RGB)×1080, FHD 176PPI
300 cd/m² (Typ.)
800:1 (Typ.) (TM)
Symmetry
a-Si TFT-LCD, LCM
eDP (2 Lanes) , eDP1.2 , 40 pins Connector
a-Si TFT-LCD, LCM
b125han02.3     12.5"    panel      lcd    for     AUO

b125han02.3 12.5" panel lcd for AUO

b125han02.3

12.5"
1920(RGB)×1080, FHD 176PPI
300 cd/m² (Typ.)
700 : 1 (Typ.) (TM)
85/85/85/85 (Typ.)(CR≥10)
WLED , 15K hours , With LED Driver
eDP (2 Lanes) , eDP1.3 , 30 pins Connector
a-Si TFT-LCD, LCM
b125xtn01.0 hw4a     12.5"     lcd    display    screens   for   AUO

b125xtn01.0 hw4a 12.5" lcd display screens for AUO

b125xtn01.0 hw4a

12.5"
1366(RGB)×768, WXGA 125PPI
200 cd/m² (Typ.)
400 : 1 (Typ.) (TM)
45/45/15/35 (Typ.)(CR≥10)
WLED , 15K hours , With LED Driver
eDP (2 Lanes) , eDP1.2 , 30 pins Connector
a-Si TFT-LCD, LCM
b125han03.0   12.5"   lcd    display   screens   for    AUO

b125han03.0 12.5" lcd display screens for AUO

b125han03.0

12.5"
1920(RGB)×1080, FHD 176PPI
300 cd/m² (Typ.)
1000 : 1 (Typ.) (TM)
85/85/85/85 (Typ.)(CR≥10)
WLED , 15K hours , With LED Driver
eDP (2 Lanes) , eDP1.2 , 30 pins Connector
a-Si TFT-LCD, LCM
