Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS
Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS
Price: $230.00
$228.00/ piece
Add to cart
Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS
Mitsubishi AA150XW02
Mitsubishi AA150XW02
Mitsubishi AA150XW02
Mitsubishi AA150XW02
Mitsubishi AA150XW02
Mitsubishi AA150XW02

Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS

Price: $230.00
$228.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS

Product Information Product Specifications
Model:
AA150XW02
Brand:
Mitsubishi
Application:
Industrial
Size:
7"
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
300
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
0.500 KG
Overview

Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS

Mitsubishi AA150XW02 is a 15.0-inch a-Si TFT-LCD industrial-grade liquid crystal module manufactured by Mitsubishi Electric. This product features 1024(RGB)×768 XGA standard resolution with 85PPI pixel density, equipped with IPS wide viewing angle display technology, 500cd/m² high brightness and 1000:1 high contrast ratio, supporting an extreme wide operating temperature range of -30°C to 80°C.


AA150XW02 adopts a WLED backlight system with a backlight life of up to 100,000 hours, no backlight driver board required, and is equipped with a 20-pin single-channel LVDS interface supporting 6/8-bit color depth. The surface is treated with 3H hardness anti-glare coating and has excellent anti-vibration capability (1.0G), specially designed for fields with extremely high requirements for display performance and environmental adaptability such as industrial automation and medical imaging.


Mitsubishi AA150XW02 Industrial LCD LVDS Highlights:

IPS full viewing angle display: Adopts IPS wide viewing angle technology with 85° viewing angles in all directions, uniform color and no viewing angle color shift

Extreme wide temperature design: Supports operating temperature from -30°C to 80°C, adapting to various harsh industrial environments such as severe cold and heat

Ultra-long life backlight: WLED backlight system life up to 100,000 hours, greatly reducing maintenance costs and replacement frequency

Industrial-grade reliability: Passed 1.0G vibration test, 3H hardness anti-glare surface, strong scratch and anti-reflection resistance

Flexible interface configuration: Supports 6/8-bit color depth switching, single-channel LVDS interface, good compatibility and easy integration


Mitsubishi AA150XW02 Industrial LCD LVDS Specification:

ParameterSpecification
Part NumberAA150XW02
BrandMitsubishi Electric
Screen Size15.0 inch
Panel Typea-Si TFT-LCD, Liquid Crystal Module (LCM)
Resolution1024(RGB)×768 [XGA]
Pixel Density85 PPI
Pixel FormatRGB Vertical Stripe
Active Area304.128(W)×228.096(H) mm
Brightness500 cd/m² (Typical)
Contrast Ratio1000:1 (Typical)
Color Depth262K/16.7M (6/8-bit)
Color Gamut72% NTSC (CIE1931)
Backlight TypeWLED, 5 strings, without driver
Backlight Life100,000 hours (Typical)
Interface TypeLVDS (1 ch, 6/8-bit), 20 pins connector
Optical ModeIPS, Normally Black, Transmissive
Viewing Angle85°/85°/85°/85° (U/D/L/R, CR≥10)
Response Time12/12 ms (Tr/Td, Typical)
Operating Temperature-30°C ~ +80°C
Storage Temperature-30°C ~ +80°C
Vibration Rating1.0G (9.8 m/s²)
Surface TreatmentMatte, 3H hardness anti-glare coating
Mechanical Dimensions326(W)×255(H)×11(D) mm (Typical)
WeightApproximately 1.05kg
Production StatusActive

Mitsubishi AA150XW02 Industrial LCD LVDS Applications:

Industrial Automation: PLC HMI, industrial robot teach pendants, production line monitoring systems, CNC machine control panels

Medical Imaging: Portable ultrasound diagnostic devices, medical monitoring equipment, laboratory analytical instruments, dental treatment equipment displays

Automotive Electronics: Special vehicle display terminals, construction machinery dashboards, in-vehicle monitoring systems, marine navigation equipment

Security Monitoring: HD surveillance monitors, video conference terminals, access control systems, public information displays

Other Applications: Aerospace equipment, petroleum exploration instruments, military command systems, outdoor industrial displays


FAQ:

Q1: What is the screen size of AA150XW02?

A1: AA150XW02 is a 15.0-inch industrial-grade LCD display, not 7 inches. Please confirm the screen size and model you need before purchasing.

Q2: What is the interface type of this screen?

A2: AA150XW02 adopts a 20-pin single-channel LVDS interface, supports 6/8-bit color depth switching, and is compatible with most industrial control systems.

Q3: Is the product an original Mitsubishi genuine product?

A3: Yes, all AA150XW02 we sell are original genuine products manufactured by Mitsubishi Electric, with quality guarantee and perfect after-sales service.


Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS

Mitsubishi AA150XW02 15.0" 1024×768 XGA IPS Wide Temp Industrial LCD LVDS

AA150XW02

7"
a-Si TFT-LCD, LCM
AA150XW01 Mitsubishi 15 inch 1024*768 Industrial LCD Screen

AA150XW01 Mitsubishi 15 inch 1024*768 Industrial LCD Screen

AA150XW01

15"
1024*768
500
1000:1
85/85/85/85
WLED
20 pins
a-Si TFT-LCD, LCM
AA150XW14  Mitsubishi  15 inch tft display

AA150XW14 Mitsubishi 15 inch tft display

AA150XW14

15"
1024*768
1000
1000 : 1
85/85/85/85
WLED
20 pins
a-Si TFT-LCD, LCM
AA150XW02 is a 7" a-Si TFT-LCD, LCM Display screen Product from Mitsubishi.According to Mitsubishi's product specification sheet,AA150XW02 display has a resolution of , Contrast Ratio is ,Viewing Angle is ,Lamp Type is ,Signal Interface is ,Brightness is .Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of AA150XW02 after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
