NL10276AC28-05R NEC 14.1 inch 1024*768 CCFL display modules
NL10276AC28-05R NEC 14.1 inch 1024*768 CCFL display modules
Price: $125.00
$119.90/ piece
Add to cart
NL10276AC28-05R NEC
NL10276AC28-05R NEC
NL10276AC28-05R NEC
NL10276AC28-05R NEC

NL10276AC28-05R NEC 14.1 inch 1024*768 CCFL display modules

Price: $125.00
$119.90/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

NL10276AC28-05R NEC 14.1 inch 1024*768 CCFL display modules

Product Information Product Specifications
Model:
NL10276AC28-05R
Brand:
NEC
Application:
Industrial
Size:
14.1"
Resolution:
1024(RGB)×768, XGA 91PPI
Brightness:
220 cd/m2 (Typ.)
Contrast Ratio:
150 : 1 (Typ.) (TM)
Viewing Angle:
50/50/20/35 (Typ.)(CR≥10)
Lamp Type:
2 pcs CCFL , With Inverter
Signal Interface:
LVDS (1 ch, 6-bit) , 20 pins Connector
Panel Type:
LVDS (1 ch, 6-bit) , 20 pins Connector
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
500
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
2.500 KG
Overview

NL10276AC28-05R is mature Japan-made NEC 14.1-inch XGA industrial TN TFT module, mass equipped on medium-sized automation workstation monitors and desktop laboratory testing instruments.250 cd/m² moderate brightness meets indoor factory, laboratory and hospital lighting environments. Gloss standard polarizer delivers sharp text and waveform display for long-time static production data monitoring; optional matte anti-glare version can eliminate overhead lamp reflection for bright workshop scenarios.


20Pin single-channel LVDS differential signal has excellent anti-electromagnetic interference performance, stable image output in light dust, slight vibration workshop environments, fully compatible with mainstream industrial ARM, PLC and FPGA control mainboards. Dual edge detachable CCFL lamp design allows maintenance personnel to replace only aging lamp tubes instead of the entire LCD module, greatly reducing on-site equipment maintenance costs. Reinforced metal backplate with standard four-corner mounting lugs supports direct plug-and-play replacement of all NL10276AC28 series screens without equipment shell cutting or wiring rework.


Full Technical Specification Table

CategoryParameterTypical Specification
Basic InfoFull Part NumberNL10276AC28-05R

ManufacturerNEC Japan Industrial XGA CCFL Series

Screen Size14.1 inch, landscape 4:3
Display CoreNative Resolution1024(RGB) × 768 XGA, 91 PPI

Panel Techa-Si TN TFT-LCD, Transmissive Normally White

Pixel ArrangementRGB vertical stripe
Optical PerformanceActive Display Area (AA)290.4(W) × 217.8(H) mm

Pixel Pitch0.2835 × 0.2835 mm

Typical Brightness250 cd/m² industrial standard brightness

Static Contrast Ratio300:1 @ 25℃ ambient

Color Depth6-bit RGB, 262K display colors, 45% NTSC gamut

Viewing Angle (CR≥10)L/R:50°, U:20°, D:35°; Optimal viewing: 6 o’clock (bottom)

Response Time (Tr/Td)22ms / 30ms, total 52ms typical

Native Refresh RateFixed 60Hz XGA timing
Mechanical SpecOverall Outline Dimension310.0(W) × 242.5(H) × 11.8(D) mm metal backplate

Net Weight~1000g industrial module

Surface TreatmentStandard glossy polarizer, matte AG anti-glare optional, 3H scratch-resistant hard coat
Electrical InterfaceLVDS Connector20Pin 0.5mm pitch single-channel 6-bit LVDS bottom FPC

Logic Supply VoltageDC 5.0V (4.7V ~ 5.3V tolerance)
Backlight SystemLight SourceDual edge two parallel CCFL cold cathode tubes (2 lamps)

Backlight HarnessIndependent 2Pin separate wire harness for high-voltage lamp power

Onboard CircuitNo built-in CCFL high-voltage boost IC; external dual-lamp CCFL inverter mandatory

CCFL Rated Lifespan40,000 hours to half brightness, detachable replaceable lamp tube structure
Environmental RatingOperating Temperature-20 ℃ ~ +70 ℃ wide industrial grade

Storage Temperature-30 ℃ ~ +80 ℃ ultra-wide storage range

Operating Humidity10% ~ 90% RH non-condensing

ESD ResistanceContact ±6KV / Air ±10KV
Quality & ComplianceQuality GradeOriginal Grade A: zero bright/dark dot, no horizontal/vertical line mura, uniform backlight without light leakage

Stock StatusIn-Stock; full pixel scan + wide temp cycling aging test before shipment

CertificationRoHS compliant, UL certified, CCFL contains trace mercury
Touch MatchingBare LCM only; separate 14.1" 4-wire resistive touch digitizer for optical bonding

Core Advantages

  1. -20 ℃ ~ +70 ℃ ultra-wide industrial temperature, stable cold startup for northern unheated factory equipment

  2. Detachable dual CCFL lamp structure, low post-maintenance cost when backlight lamp aging

  3. Classic 4:3 XGA 1024×768 resolution, ultra-high compatibility with vintage industrial control firmware

  4. Compact 20Pin single-channel LVDS interface, abundant industrial monitor & PLC driver matching resources

  5. 40,000-hour long-life dual CCFL backlight, reduce maintenance downtime for 24/7 uninterrupted production equipment

  6. Japan original NEC industrial production process, ultra-low pixel/mura defect rate for bulk machinery maintenance orders

  7. Reinforced metal backplate with high ESD protection, suitable for high-static electricity workshop production lines

  8. Ready original surplus spot stock supports fast delivery for old industrial equipment urgent repair orders

Typical Application Scenarios

  1. Replacement XGA display for 14.1-inch vintage CNC lathe, injection molding, textile machinery workstation HMI panels

  2. Portable medical blood/ECG analytical equipment real-time parameter & waveform monitoring screen

  3. Laboratory precision analytical instrument long-period data recorder desktop monitoring terminal

  4. Factory automation central control room real-time production data industrial monitor

  5. Early-generation embedded industrial all-in-one PC fixed cabinet data display screen

  6. Spare replacement module for NEC NL10276AC28 series 14.1-inch dual CCFL XGA industrial TFT LCM

 FAQ

Q1: Does NL10276AC28-05R need an external CCFL inverter?

A1: Yes. There is no onboard dual-lamp CCFL high voltage boost IC. Matched dual-channel CCFL high voltage inverter is mandatory to light the backlight; WLED constant current drivers cannot substitute without circuit refitting.

Q2: What is the minimum operating temperature of this panel?

A2: Supports normal cold startup and stable continuous operation at -20℃, suitable for northern cold factory and cold storage monitoring equipment.

Q3: Can NL10276AC28-05D directly replace NL10276AC28-05R?

A3: Mechanical outline, mounting holes and 20Pin LVDS pinout are fully consistent; verify dual CCFL lamp voltage/current and XGA timing parameters before plug-and-play installation.

Q4: Is this screen suitable for outdoor sunlight readable use?

A4: Standard 250cd/m² indoor brightness, only applicable for indoor workshop/laboratory environments; not recommended for outdoor direct sunlight scenarios.

Q5: Does the LCM come with touch panel as standard?

A5: Bare LCD module only without touch sensor layer. Separate matched 14.1-inch 4-wire resistive touch digitizer needs optical bonding to form touch industrial HMI assembly.

Q6: Are panels available in stock and ready for shipment?

A6: Yes, tested Grade A original NEC Japan-made modules are warehoused. Shipment within 1–3 working days after order confirmation, every unit completes full pixel and backlight uniformity inspection before delivery.


Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
NL10276AC28-05R NEC 14.1 inch 1024*768 CCFL display modules

NL10276AC28-05R NEC 14.1 inch 1024*768 CCFL display modules

NL10276AC28-05R

14.1"
1024(RGB)×768, XGA 91PPI
220 cd/m2 (Typ.)
150 : 1 (Typ.) (TM)
50/50/20/35 (Typ.)(CR≥10)
2 pcs CCFL , With Inverter
LVDS (1 ch, 6-bit) , 20 pins Connector
LVDS (1 ch, 6-bit) , 20 pins Connector
NL10276KC30-43DD NLT 15 inch 1024*768 lcd display panel

NL10276KC30-43DD NLT 15 inch 1024*768 lcd display panel

NL10276KC30-43DD

15"
1024(RGB)×768, XGA, 4:3
450 cd/m² (Typ.)
600:1 (Typ.) (TM)
80/80/80/80 (Typ.)(CR≥10
6 strings WLED, 70K hrs, Without Driver
LVDS (1 ch, 8-bit), 20 pins Connector
a-Si TFT-LCD, LCM
NL10276HC20-39  NEC 10.4  inch 1024*768 lcd display screens

NL10276HC20-39 NEC 10.4 inch 1024*768 lcd display screens

NL10276HC20-39

10.4"
1024(RGB)×768, 4:3, XGA
a-Si TFT-LCD, LCM
NL10276AC28-05R is a 14.1" LVDS (1 ch, 6-bit) , 20 pins Connector Display screen Product from NEC.According to NEC's product specification sheet,NL10276AC28-05R display has a resolution of 1024(RGB)×768, XGA 91PPI, Contrast Ratio is 150 : 1 (Typ.) (TM),Viewing Angle is 50/50/20/35 (Typ.)(CR≥10),Lamp Type is 2 pcs CCFL , With Inverter,Signal Interface is LVDS (1 ch, 6-bit) , 20 pins Connector,Brightness is 220 cd/m2 (Typ.).Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of NL10276AC28-05R after packaging is 2.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
