G043FTT01.0 AUO 4.3" a-Si TFT-LCD LCM 480(RGB)×272 WQVGA 128PPI

G043FTT01.0 AUO 4.3" a-Si TFT-LCD LCM 480(RGB)×272 WQVGA 128PPI

Price: $25.00

$20.00/ Price

Delivery:

Payment:

Calculate shipping price

Require:*

Product Model*	Target price	Qty *

Message

Your contact info:

Additional info:

Name: *

Mr.

Ms.

1. Quote with shipping freight?

Email : *

YES

Phone:

2. Which carrier do you perfert?

Company:

	Fedex		UPS		DHL
	TNT		other

Country:*

Specifications Ordering instructions Overview Product Comparison Q&A Reviews

G043FTT01.0 AUO 4.3" a-Si TFT-LCD LCM 480(RGB)×272 WQVGA 128PPI

Product Information Product Specifications

Model:

G043FTT01.0

Brand:

AUO

Application:

Industrial

Size:

4.3"

Resolution:

480(RGB)×272, WQVGA 128PPI

Brightness:

400 cd/m² (Typ.)

Contrast Ratio:

400:1 (Typ.) (TM)

Viewing Angle:

65/65/50/55(Typ.)(CR≥10)

Lamp Type:

9S1PWLED, 10K hours, Without Driver

Signal Interface:

ParallelRGB(1ch,8-bit),45pinsFPC

Panel Type:

a-Si TFT-LCD, LCM

Pixel Format:

RGB Vertical Stripe

Active Area:

95.04(W)×53.856(H) mm

Bezel Opening:

100.8(W)×58.76(H) mm

Outline size:

105.5(W)×67.2(H)×4.33(D) mm

Surface:

Antiglare(Haze8%),Hardcoating(3H) Brightness

Response Time:

Best View on:

6o'clock

Work Mode:

TN, Normally White, Transmissive

Display Colors:

16.7M50%NTSC

Weight:

59.0g(Typ.)

Frequency:

60Hz

Touchscreen:

4-wire Resistive Touch

Signal Type:

ParallelRGB(1ch,8-bit),45pinsFPC

Voltage Supply:

3.3/3.3V(Typ.)(VDD/VDDIO)

Ordering instructions

Quality:

test ok before ship it

RMA Policy:

RMA 6 month

Sample:

Paid Sample

Stock:

319

Stock Location:

China

Delivery:

WorldWide

Lead Time:

1-3 Days

Weight:

0.500 KG

Overview

Product display

Product Comparison

Model:

Size:

Resolution:

Brightness:

Contrast Ratio:

Viewing Angle:

Lamp Type:

Signal Interface:

Panel Type:

G043FTT01.0 AUO 4.3" a-Si TFT-LCD LCM 480(RGB)×272 WQVGA 128PPI

G043FTT01.0

4.3"

480(RGB)×272, WQVGA 128PPI

400 cd/m² (Typ.)

400:1 (Typ.) (TM)

65/65/50/55(Typ.)(CR≥10)

9S1PWLED, 10K hours, Without Driver

ParallelRGB(1ch,8-bit),45pinsFPC

a-Si TFT-LCD, LCM

TCG043WQLBAANN-GN50 4.3 inch 480(RGB)×272 lcd display panel

TCG043WQLBAANN-GN50

4.3"

480(RGB)×272

800 cd/m²

350 : 1

70/70/60/65

WLED , 100K hours , No Driver

Parallel RGB (1 ch, 8-bit) , 40 pins FPC

a-Si TFT-LCD, LCM

TCG043WQLBAANN-GN00 industrial lcd screen 4.3 inch 105.5(W)×67.2(H)×6.2(D) mm

TCG043WQLBAANN-GN00

480(RGB)×272, WQVGA 128PPI

450 cd/m² (Typ.)

350:1 (Typ.) (TM)

70/70/60/65 (Typ.)(CR≥10)

WLED , 70K hours , Without Driver

Parallel RGB (1 ch, 8-bit) , 40 pins FPC

a-Si TFT-LCD, LCM

G043FW01 V0 tft lcd module 105.7(W)×67.4(H) mm 4.3 inch

G043FW01 V0

4.3"

480(RGB)×272, WQVGA 128PPI

450 cd/m² (Typ.)

400 : 1 (Typ.) (TM)

65/65/50/55 (Typ.)(CR≥10)

WLED , 30K hours , No Driver

Parallel RGB (1 ch, 8-bit) , FPC 45 pins

a-Si TFT-LCD, LCM

G043FTT01.0 is a 4.3" a-Si TFT-LCD, LCM Display screen Product from AUO.According to AUO's product specification sheet,G043FTT01.0 display has a resolution of 480(RGB)×272, WQVGA 128PPI, Contrast Ratio is 400:1 (Typ.) (TM),Viewing Angle is 65/65/50/55(Typ.)(CR≥10),Lamp Type is 9S1PWLED, 10K hours, Without Driver,Signal Interface is ParallelRGB(1ch,8-bit),45pinsFPC,Brightness is 400 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of G043FTT01.0 after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
