TM065JYSP01 Tianma 6.5" a-Si TFT-LCD  CELL    720(RGB)×1280  WXGA  226PPI
TM065JYSP01 Tianma 6.5" a-Si TFT-LCD CELL 720(RGB)×1280 WXGA 226PPI
Der Preis: €76.96
€70.62/ Mitglied
In den Warenkorb
TM065JYSP01 Tianma 6.5" a-Si TFT-LCD  CELL    720(RGB)×1280  WXGA  226PPI
TM065JYSP01 Tianma 6.5" a-Si TFT-LCD  CELL    720(RGB)×1280  WXGA  226PPI

TM065JYSP01 Tianma 6.5" a-Si TFT-LCD CELL 720(RGB)×1280 WXGA 226PPI

Der Preis: €76.96
€70.62/ Mitglied
Lieferung:
Zahlung:
Berechnung der fracht
Erforderlich:*
Produktmodell* Zielpreis Qty *
Nachricht
Ihre Kontaktdaten: Weitere Informationen:
Name: *
Herr. Frau.
1. Angebot mit Versand Fracht?
Email : *
JA NEIN
Telefon: 2. Welchen Carrier perfert ihr??
Unternehmen:
Fedex UPS DHL
TNT andere
Land:*

TM065JYSP01 Tianma 6.5" a-Si TFT-LCD CELL 720(RGB)×1280 WXGA 226PPI

Produktinformationen Produktspezifikationen
Modell:
TM065JYSP01
Marke:
TIANMA
Anwendung:
Industrie
Größe:
Entschließung:
720(RGB)×1280, WXGA 226PPI
Helligkeit:
0 cd/m²
Kontrastverhältnis:
1000:1 (Typ.) (TM)
Betrachtungswinkel:
BestViewon
Lampentyp:
Driver IC
Signalschnittstelle:
BestViewon
Panel-Typ:
a-Si TFT-LCD, CELL , Full Cell
Pixelformat:
RGB Vertical Stripe
Aktiver Bereich:
80.598(W)×143.232(H) mm
Lünette Öffnung:
-
Umrissgröße:
83.168(W)×151.3(H) mm
Oberfläche:
-
Ansprechzeit:
35 (Typ.)(Tr+Td)
Beste Ansicht:
GlassDepth
Arbeitsmodus:
-
Anzeigefarben:
Frequency
Gewicht:
-
Frequenz:
Weight
Touchscreen:
Without
Signaltyp:
BestViewon
Spannungsversorgung:
-
Bestellanleitung
Qualität:
test ok before ship it
Größe:
RMA 6 month
Entschließung:
Paid Sample
Lagerbestand:
28
Betrachtungswinkel:
China
Lampentyp:
WorldWide
Signalschnittstelle:
1-3 Days
Gewicht:
0.500 KG
Übersicht

Produkteinführung

Das TIANMA TM065JYSP01 ist eine 6,5-Zoll-a-Si-TFT-LCD-Zelle, die für Mobiltelefone sowie kompakte Handheld-Displaybaugruppen entwickelt wurde. Sie bietet eine WXGA-Auflösung von 720 (RGB) × 1280 Pixeln mit einer Pixeldichte von 226 PPI und verbindet eine detaillierte Bildwiedergabe mit einer praktischen Panelgröße für platzsparende Baukonstruktionen. Der FFS-Betriebsmodus Normal Black, die Farbtiefe von 16,7 Mio. Farben und die auf CIE 1931 basierende sRGB-Abdeckung von 87 % unterstützen eine klare Farbdarstellung in alltäglichen mobilen Benutzeroberflächen. Zu den typischen Spezifikationen gehören ein transmissives Kontrastverhältnis von 1000:1, eine Reaktionszeit von 35 ms sowie eine Bildwiederholrate von 60 Hz. Mit dem angegebenen Betriebstemperaturbereich von -20°C bis 70°C eignet sich das Display für die Integration in Mobilgeräte, die eine konsistente visuelle Leistung unter unterschiedlichen Umgebungsbedingungen benötigen. Die definierten Außenmaße und die Abmessungen der aktiven Fläche bieten Konstrukteuren belastbare Grundlagen für die Entwicklung mechanischer Gehäuse und Displaybaugruppen.

Wichtige Merkmale

  • Die WXGA-Auflösung von 720 (RGB) × 1280 Pixeln und die Pixeldichte von 226 PPI ermöglichen eine detaillierte Bilddarstellung in mobilen Benutzeroberflächen und bleiben gleichzeitig mit effizienten Panelabmessungen vereinbar.

  • Der FFS-Betriebsmodus Normal Black unterstützt konstante Schwarztöne und eignet sich für Mobiltelefone sowie kompakte Handheld-Displayanwendungen.

  • Ein typisches transmissives Kontrastverhältnis von 1000:1 und eine Reaktionszeit von 35 ms unterstützen eine klare visuelle Darstellung und eine praxistaugliche Interaktionsperformance.

  • 16,7 Mio. Farben bei einer Farbtiefe von 8 Bit sowie eine auf CIE 1931 basierende sRGB-Abdeckung von 87 % ermöglichen einen breiten Farbbereich für Standardinhalte auf Mobilgeräten.

  • Die Bildwiederholrate von 60 Hz bildet eine geeignete Displaygrundlage für häufig aktualisierte mobile Benutzeroberflächen.

  • Die angegebenen Betriebs- und Lagertemperaturbereiche von -20°C bis 70 °C beziehungsweise -30°C bis 80 °C erleichtern die Planung für Betriebs- und Ruhezustände.

  • Die definierten Außenmaße von 83,168 × 151,3 mm und die aktive Fläche von 80,598 × 143,232 mm bieten klare Bezugsmaße für die mechanische Integration und die Entwicklung von Displaybaugruppen.

Anwendungen

  • Displaybaugruppen für Mobiltelefone

  • Kompakte elektronische Handheld-Geräte

  • Benutzeroberflächen-Displays für Mobilgeräte

Häufig gestellte Fragen

Q1: Welche Auflösung und Pixeldichte bietet das TM065JYSP01?

A: Das TIANMA TM065JYSP01 bietet auf einem 6,5-Zoll-Panel eine WXGA-Auflösung von 720 (RGB) × 1280 Pixeln mit einer Pixeldichte von 226 PPI.

Q2: Welche Displaytechnologie und welcher Betriebsmodus werden beim TM065JYSP01 eingesetzt?

A: Das Panel verwendet die a-Si-TFT-LCD-Zellentechnologie im FFS-Betriebsmodus Normal Black.

Q3: Wie unterstützen Kontrastverhältnis und Reaktionszeit des Panels das Anwendungsdesign?

A: Das typische transmissive Kontrastverhältnis beträgt 1000:1, die typische Reaktionszeit 35 ms, gemessen als Tr+Td. Diese Werte liefern Konstrukteuren grundlegende Leistungsdaten zur Bewertung der Eignung als Mobilgeräte-Display.

Q4: Welche Farbeigenschaften sind für das TM065JYSP01 angegeben?

A: Das Panel unterstützt 16,7 Mio. Farben bei einer Farbtiefe von 8 Bit, mit einer angegebenen Farbtemperatur von 6715 K und einer auf CIE 1931 basierenden sRGB-Abdeckung von 87 %.

Q5: Welche Betriebs- und Lagertemperaturbereiche gelten?

A: Der angegebene Betriebstemperaturbereich liegt bei -20°C bis 70 °C, der Lagerungstemperaturbereich bei -30°C bis 80 °C.

Q6: Wie groß sind die Außenmaße und die aktive Fläche des Panels?

A: Die Außenmaße betragen 83,168 × 151,3 mm (H × V), die aktive Fläche misst 80,598 × 143,232 mm (H × V).

Q7: Welcher Pixelabstand und welche Bildwiederholrate sind angegeben?

A: Der Pixelabstand beträgt 0,0373 × 0,1119 mm (H × V), die angegebene Bildwiederholrate liegt bei 60 Hz.

Q8: Für welche Produkttypen eignet sich das TM065JYSP01?

A: Das Panel ist für Mobiltelefone, Displaybaugruppen für Mobilgeräte sowie kompakte elektronische Handheld-Geräte vorgesehen.

TM065JYSP01 is a 6.5" a-Si TFT-LCD, CELL , Full Cell Display screen Product from TIANMA.According to TIANMA's product specification sheet,TM065JYSP01 display has a resolution of 720(RGB)×1280, WXGA 226PPI, Contrast Ratio is 1000:1 (Typ.) (TM),Viewing Angle is BestViewon,Lamp Type is Driver IC,Signal Interface is BestViewon,Brightness is 0 cd/m².Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of TM065JYSP01 after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
