AUO P429KVN01.1 43 Zoll LCD für Industriesteuerung
AUO P429KVN01.1 43 Zoll LCD für Industriesteuerung
Der Preis: €280.67
€271.62/ Mitglied
In den Warenkorb
P429KVN01.1     43
P429KVN01.1     43

AUO P429KVN01.1 43 Zoll LCD für Industriesteuerung

Der Preis: €280.67
€271.62/ Mitglied
Lieferung:
Zahlung:
Berechnung der fracht
Erforderlich:*
Produktmodell* Zielpreis Qty *
Nachricht
Ihre Kontaktdaten: Weitere Informationen:
Name: *
Herr. Frau.
1. Angebot mit Versand Fracht?
Email : *
JA NEIN
Telefon: 2. Welchen Carrier perfert ihr??
Unternehmen:
Fedex UPS DHL
TNT andere
Land:*

AUO P429KVN01.1 43 Zoll LCD für Industriesteuerung

Produktinformationen Produktspezifikationen
Modell:
P429KVN01.1
Marke:
AUO
Anwendung:
Hohe Helligkeit im Freien
Entschließung:
2880(RGB)×540 68PPI
Kontrastverhältnis:
4000:1 (Typ.) (TM)
Betrachtungswinkel:
89/89/89/89 (Typ.)(CR≥10)
Signalschnittstelle:
eDP (4 Lanes) , HBR2 (5.4G/lane) , 51 pins Connector
Panel-Typ:
a-Si TFT-LCD, LCM
Bestellanleitung
Qualität:
test ok before ship it
Größe:
RMA 6 month
Entschließung:
Paid Sample
Lagerbestand:
300
Betrachtungswinkel:
China
Lampentyp:
WorldWide
Signalschnittstelle:
1-3 Days
Gewicht:
5.500 KG
Übersicht

Produkteinführung

Das AUO P429KVN01.1 ist eine 43-Zoll-a-Si-TFT-LCD-Zelle für die Integration in professionelle Industri Displays. Ihre ultrabreite native Auflösung von 2880(RGB)×540 bietet ausreichend Fläche für Statusdashboards, Prozessvisualisierungen und mehrspaltige Informationslayouts. Mit 68 PPI werden detaillierte Betriebsdaten klar dargestellt. Der transmissive AMVA3-Modus im Normally-Black-Prinzip liefert typischerweise ein Kontrastverhältnis von 4000:1, während die auf CIE 1931 basierende sRGB-Farbraumabdeckung von 88 % für eine konsistente Farbwiedergabe in unterstützten Displaysystemen sorgt. Die weiten Blickwinkel verbessern die Lesbarkeit in Leitständen und anspruchsvollen Installationsumgebungen. Dank der eDP-Schnittstelle mit vier HBR2-Lanes, einer typischen Reaktionszeit von 16 ms (Grau zu Grau) und einer Bildwiederholfrequenz von 60 Hz eignet sich das Panel für industrielle Überwachung, Leitstandanwendungen und kommerzielle Informationsdisplays, bei denen zuverlässige Integration und konsistente Lesbarkeit entscheidend sind.

Wichtige Merkmale

  • Die ultrabreite native Auflösung von 2880(RGB)×540 bei 68 PPI bietet eine erweiterte Darstellungsfläche für Industriescreens, Statusinformationen und mehrspaltige Layouts.

  • Der transmissive AMVA3-Modus im Normally-Black-Prinzip unterstützt ein typisches Kontrastverhältnis von 4000:1 und sorgt damit für eine klare visuelle Abgrenzung in professionellen Displaysystemen.

  • Die weiten Blickwinkel von 89/89/89/89 Grad gewährleisten eine konsistente Sichtbarkeit bei unterschiedlichen Installationspositionen und Betrachtungsrichtungen.

  • Die eDP-Schnittstelle mit vier HBR2-Lanes und 5,4 Gbps pro Lane ermöglicht eine hochbandbreitige Verbindung mit kompatiblen Systemlösungen.

  • Die typische Reaktionszeit von 16 ms (Grau zu Grau) und die Bildwiederholfrequenz von 60 Hz unterstützen eine reaktionsschnelle Darstellung häufig wechselnder Überwachungs- und Prozesssteuerungsinformationen.

  • Die auf CIE 1931 basierende sRGB-Farbraumabdeckung von 88 % und die Farbtemperatur von 7175 K definieren die Farbeigenschaften für die applikationsspezifische Displaykalibrierung.

  • Die typische Konturbreite von 1,4 mm und das typische Gewicht von 1,50 kg erleichtern die Integration in platzsparende Industrieausrüstungen und Panelsysteme.

  • Die angegebenen Betriebs- und Lagertemperaturbereiche bieten Entwicklern, Integratoren und Konstruktoren von Ausrüstungen eine Grundlage für die Umwelt- und Auslegungsplanung.

Anwendungen

  • Industrielle Leitstand- und Command-Center-Displaysysteme

  • Werksüberwachung und Prozessvisualisierung

  • Industrielle Ausrüstung und eingebettete Human-Machine-Interfaces

  • Digital Signage und kommerzielle Informationsdisplaysysteme

  • Transportinformations- und Fahrgastinformationsdisplays

  • Sicherheitsüberwachung und Multiscreen-Visualisierung

Häufig gestellte Fragen

Q1: Welche native Auflösung und Pixeldichte bietet das AUO P429KVN01.1?

A: Das Panel verfügt über eine native Auflösung von 2880(RGB)×540 und eine Pixeldichte von 68 PPI. Dadurch lassen sich breitformatige industrielle Informationen detailliert darstellen.

Q2: Welche Displaytechnologie und welchen visuellen Modus verwendet das P429KVN01.1?

A: Es verwendet eine a-Si-TFT-LCD-Zelle im transmissiven AMVA3-Modus im Normally-Black-Prinzip.

Q3: Welches Kontrastverhältnis und welche Reaktionszeit sind für das Panel angegeben?

A: Das typische Kontrastverhältnis beträgt 4000:1, die typische Reaktionszeit von Grau zu Grau liegt bei 16 ms.

Q4: Welche Schnittstelle stellt das P429KVN01.1 für die Systemintegration bereit?

A: Das Panel verwendet eine eDP-Schnittstelle mit vier HBR2-Lanes, die jeweils mit 5,4 Gbps betrieben werden.

Q5: Welche Blickwinkel und welche Farbraumabdeckung sind verfügbar?

A: Die angegebenen Blickwinkel betragen 89/89/89/89 Grad. Die auf CIE 1931 basierende Farbraumabdeckung liegt bei 88 % sRGB.

Q6: Welche Betriebs- und Lagertemperaturbereiche sind angegeben?

A: Der angegebene Betriebstemperaturbereich liegt bei 0 bis 50 °C, der Lagertemperaturbereich bei -20 bis 60 °C.

Q7: Wie groß ist der aktive Bereich, und welche physischen Merkmale weist das Panel auf?

A: Der aktive Bereich misst 1071,36 × 200,88 mm. Die typische Konturbreite beträgt 1,4 mm, das typische Gewicht 1,50 kg.

Q8: Welche Betriebsspannung und Bildwiederholfrequenz sind angegeben?

A: Das Panel hat eine typische Betriebsspannung von 12 V und eine Bildwiederholfrequenz von 60 Hz.
