NV133WUM-N44 BOE 13.3inch 1920×1200 lcd display screens
NV133WUM-N44 BOE 13.3inch 1920×1200 lcd display screens
BOE NV133WUM-N44 is a high-performance laptop-specific LCD module launched by BOE Technology Group, adopting BOE's self-developed ADS (Advanced Super Dimension Switch) wide viewing angle display technology, providing 85°/85°/85°/85° full viewing angle visibility with excellent color and brightness uniformity and no viewing angle color shift.
It is equipped with 1920×1200 WUXGA high resolution and 16:10 golden display ratio, which increases vertical display space by 18% compared to traditional 16:9 screens, significantly improving office and browsing experience. It supports 16.77 million true color display with 45% NTSC color gamut coverage, delivering accurate and natural color reproduction. The 300cd/m² standard brightness design meets daily indoor use requirements.
It features a WLED backlight system with integrated LED driver, with a backlight life of up to 15,000 hours. It adopts eDP 1.2 2-lane interface, supporting HBR1 (2.7G/lane) high-speed transmission, with a 30-pin standard connector for strong compatibility. The ultra-thin 5mm body design is lightweight and easy to integrate into various thin and light laptops and portable devices.
NV133WUM-N44 BOE lcd display screens Highlights:
ADS wide viewing angle technology: 85° full viewing angle visibility, excellent color and brightness uniformity, no viewing angle color shift
16:10 golden ratio: 18% more vertical display space than 16:9 screens, better office and browsing experience
WUXGA high resolution: 1920×1200 resolution, 170PPI pixel density, clear and delicate images
Standard brightness design: 300cd/m² brightness, meets daily indoor use requirements
High-speed eDP interface: eDP 1.2 2-lane interface, supports 2.7G/lane high-speed transmission, 30-pin standard connector
Ultra-thin body design: Only 5mm thickness, lightweight, easy to integrate into thin and light laptops and portable devices
Reliable quality assurance: BOE original production, strict quality control process, stable product performance
NV133WUM-N44 BOE lcd display screens Specifications:
| Parameter Category | Detailed Specifications |
|---|---|
| Basic Information | |
| Brand | BOE Technology Group |
| Model | NV133WUM-N44 |
| Product Series | NV133WUM |
| Panel Type | a-Si TFT-LCD, LCM |
| Display Size | 13.3 inch |
| Aspect Ratio | 16:10 |
| Display Specifications | |
| Resolution | 1920(RGB)×1200 (WUXGA) |
| Pixel Density | 170PPI |
| Pixel Arrangement | RGB Vertical Stripe |
| Display Colors | 16.77M (24-bit) |
| Color Gamut | 45% NTSC (CIE1931) |
| Brightness | 300cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | ADS, Normally Black, Transmissive |
| Response Time | 30ms (Tr+Td, Typ.) |
| Viewing Angle | 85°/85°/85°/85°(L/R/U/D, CR≥10) |
| Refresh Rate | 60Hz |
| Backlight Specifications | |
| Backlight Type | WLED (White LED) |
| Backlight Configuration | 10S4P |
| Backlight Driver | Integrated LED Driver |
| Backlight Life | ≥15,000 hours |
| Interface Specifications | |
| Signal Interface | eDP (2 lanes) |
| Interface Version | eDP 1.2 HBR1 (2.7G/lane) |
| Connector Pins | 30 pins |
| Input Voltage | 3.3V (Typ.) |
| Mechanical Specifications | |
| Active Area | 286.042(W)×178.776(H)mm |
| Outline Dimensions | 291.74(W)×189.53(H)×5.0(D)mm |
| Surface Treatment | Matte, Anti-glare |
| Touch Function | None |
| Weight | Approx. 0.25kg |
| Environmental Specifications | |
| Operating Temperature | 0℃ ~ +50℃ |
| Storage Temperature | -20℃ ~ +60℃ |
| Operating Humidity | 10%~90%RH (non-condensing) |
| Certifications & Compliance | |
| RoHS | Compliant |
| Product Certifications | CE, FCC |
NV133WUM-N44 BOE lcd display screens Applications:
Laptop computers: Screen replacement and upgrade for mainstream thin and light laptops, business laptops, student laptops
Industrial portable devices: Portable industrial computers, data collectors, handheld terminals
Medical equipment: Portable medical instruments, monitors, diagnostic equipment display terminals
In-vehicle devices: In-vehicle navigation, in-vehicle entertainment systems, driving recorders
Security equipment: Portable surveillance displays, access control systems, building intercom
Educational equipment: E-books, learning machines, teaching all-in-one machines
Consumer electronics: Tablet computers, portable players, digital photo frames
Test and measurement: Portable oscilloscopes, signal generators, industrial testing instruments
FAQ:
Q: What is the difference between NV133WUM-N44 and NV133WUM-N41/N42?
A: NV133WUM-N41 has a brightness of 250cd/m², while NV133WUM-N42 and NV133WUM-N44 both have a brightness of 300cd/m². Other main parameters are basically the same, and the interface and size are fully compatible.
Q: What is the interface definition of this display?
A: It adopts a standard 30-pin eDP 2-lane interface. For specific pin definitions, please refer to BOE's official datasheet, and we can also provide technical support.
Q: Does this screen support touch function?
A: The standard NV133WUM-N44 does not have touch function. If you need a touch version, you can choose a matching capacitive touch screen for integration.
