M300DAN01.0  30 inch  display lcd  for AUO
M300DAN01.0 30 inch display lcd for AUO
Price: $369.00
$365.00/ piece
Add to cart
M300DAN01.0  30 inch  display lcd  for AUO
M300DAN01.0  AUO30 inch  display lcd
M300DAN01.0  30 inch  display lcd  for AUO
M300DAN01.0  AUO30 inch  display lcd

M300DAN01.0 30 inch display lcd for AUO

Price: $369.00
$365.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

M300DAN01.0 30 inch display lcd for AUO

Product Information Product Specifications
Model:
M300DAN01.0
Brand:
AUO
Application:
Desktop Monitor
Resolution:
2560(RGB)×1080, CSHD 94PPI
Brightness:
300 cd/m² (Typ.)
Viewing Angle:
89/89/89/89 (Typ.)(CR≥10)
Lamp Type:
WLED
Signal Interface:
eDP (4 Lanes) , HBR2 (5.4G/lane)
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
200
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
6.500 KG
Overview

Product Introduction

The AUO M300DAN01.0 is a 30-inch a-Si TFT-LCD LCM designed for desktop monitor applications. It features a 200Hz refresh rate, 300-nit brightness, 16.7M color depth, and a normally black transmissive AHVA display mode. Its operating temperature range of 0–50 °C makes it suitable for integration into compatible industrial and commercial desktop monitor systems.

Key Features

  • 30-inch a-Si TFT-LCD LCM

  • 200Hz refresh rate

  • 300-nit brightness

  • 7M color depth with 8-bit color

  • AHVA normally black transmissive display mode

  • 5 ms typical gray-to-gray response time

  • 432 × 291.276 mm active area

  • 0899 × 0.2697 mm pixel pitch

  • Operating temperature range of 0–50 °C

  • Storage temperature range of -20–60 °C

Technical Specifications

Panel ModelM300DAN01.0
Panel Typea-Si TFT-LCD, LCM
Display Size30
Pixel Pitch0.0899×0.2697 mm
Application FieldDesktop Monitor
Operating Temperature0 ~ 50 °C
Storage Temperature-20 ~ 60 °C
Brightness300
Response Time5 (Typ.)(G to G) (ms)
Color Depth16.7M (8-bit)
Display ModeAHVA, Normally Black, Transmissive
Refresh Rate200Hz
Active Area690.432×291.276 mm

Applications

  • Desktop monitors

  • Industrial display systems requiring a 30-inch panel

  • Commercial display equipment

  • Integrated monitor assemblies

Frequently Asked Questions

Q1: What display technology does the AUO M300DAN01.0 use?

A: The M300DAN01.0 uses a-Si TFT-LCD technology in an LCM configuration.

Q2: What is the refresh rate of the M300DAN01.0?

A: The panel has a 200Hz refresh rate.

Q3: What brightness and color depth does the panel provide?

A: The panel provides 300-nit brightness and 16.7M color depth with 8-bit color.

Q4: What is the typical response time of the M300DAN01.0?

A: The typical gray-to-gray response time is 5 ms.

Q5: What are the panel's operating and storage temperature ranges?

A: The operating temperature range is 0–50 °C, while the storage temperature range is -20–60 °C.

Q6: What are the active area and pixel pitch of the M300DAN01.0?

A: The active area measures 690.432 × 291.276 mm, and the pixel pitch is 0.0899 × 0.2697 mm.

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
M300DAN01.0  30 inch  display lcd  for AUO

M300DAN01.0 30 inch display lcd for AUO

M300DAN01.0

2560(RGB)×1080, CSHD 94PPI
300 cd/m² (Typ.)
89/89/89/89 (Typ.)(CR≥10)
WLED
eDP (4 Lanes) , HBR2 (5.4G/lane)
a-Si TFT-LCD, LCM
M300DAN01.1 30 inch lcd panel  for AUO

M300DAN01.1 30 inch lcd panel for AUO

M300DAN01.1

2560(RGB)×1080, CSHD 94PPI
300 cd/m² (Typ.)
1000:1 (Typ.) (TM)
89/89/89/89 (Typ.)(CR≥10)
WLED [10S4P] , 30K hours , W/O Driver
LVDS (4 ch, 8-bit) , 92 pins Connector
a-Si TFT-LCD, LCM
M300DVR01.0 30" UltraWide Curved LCD Panel AUO 2560×1080 Display

M300DVR01.0 30" UltraWide Curved LCD Panel AUO 2560×1080 Display

M300DVR01.0

2560(RGB)×1080, CSHD 94PPI
300 cd/m² (Typ.)
3000 : 1 (Typ.) (TM)
89/89/89/89 (Typ.)(CR≥10)
4 strings × 2CN WLED , 30K hours , No Driver
V-by-One 8 lane , Connector 51 pins
a-Si TFT-LCD, LCM
M300DAN01.0 is a a-Si TFT-LCD, LCM Display screen Product from AUO.According to AUO's product specification sheet,M300DAN01.0 display has a resolution of 2560(RGB)×1080, CSHD 94PPI, Contrast Ratio is ,Viewing Angle is 89/89/89/89 (Typ.)(CR≥10),Lamp Type is WLED,Signal Interface is eDP (4 Lanes) , HBR2 (5.4G/lane),Brightness is 300 cd/m² (Typ.).Based on its characteristics, this model is recommended for application in Desktop Monitor and other products.The weight of M300DAN01.0 after packaging is 6.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
