Der Preis: €54.32
€49.80/ Mitglied
In den Warenkorb

Der Preis: €54.32
€49.80/ Mitglied
Lieferung:
Zahlung:
Berechnung der fracht
Erforderlich:*
Produktmodell* Zielpreis Qty *
Nachricht
Ihre Kontaktdaten: Weitere Informationen:
Name: *
Herr. Frau.
1. Angebot mit Versand Fracht?
Email : *
JA NEIN
Telefon: 2. Welchen Carrier perfert ihr??
Unternehmen:
Fedex UPS DHL
TNT andere
Land:*

Datasheets:
Produktinformationen Produktspezifikationen
Modell:
ls013b7dh06
Marke:
SHARP
Anwendung:
Tabletten
Entschließung:
128(RGB)×128 136PPI
Kontrastverhältnis:
25:1 (Typ.) (RF)
Betrachtungswinkel:
60/60/60/60 (Typ.)(CR≥2)
Lampentyp:
No B/L
Signalschnittstelle:
5.0/5.0/3.0V (Typ.)(VDDA/VDD/VIH)
Panel-Typ:
a-Si TFT-LCD, LCM
Bestellanleitung
Qualität:
test ok before ship it
Größe:
RMA 6 month
Entschließung:
Paid Sample
Lagerbestand:
115
Betrachtungswinkel:
China
Lampentyp:
WorldWide
Signalschnittstelle:
1-3 Days
Gewicht:
0.500 KG
Übersicht

Produkteinführung

Das Sharp LS013B7DH06 ist ein kompaktes 1,33-Zoll-CG-Silicon-reflektives LCD-Modul für Wearables und portable elektronische Systeme mit knappem Bauraum. Die quadratische aktive Fläche von 23,808 × 23,808 mm bietet eine praxistaugliche kleine Displayoption für Statusinformationen, einfache Symbole und monochrome Benutzeroberflächen. Die flache Bauhöhe von 0,75 mm und das typische Gewicht von 1,25 g erleichtern die Integration, ohne das Gehäuse nennenswert zu vergrößern. Der reflektive Betriebsmodus sorgt für eine klare monochrome Darstellung. Das typische Kontrastverhältnis von 25:1 sowie die typischen Anstiegs- und Abfallzeiten von 10/20 ms eignen sich für Anwendungen, die eine gut lesbare, unkomplizierte visuelle Rückmeldung benötigen. Die SPI-Schnittstelle ermöglicht eine platzsparende Systemintegration, während die Farbtiefe von 1 Bit die Verarbeitung der Anzeigedaten vereinfacht. Die angegebenen Betriebs- und Lagertemperaturbereiche machen das Modul für Consumer-Wearables, am Handgelenk getragene Messgeräte und andere stromsparende portable Geräte geeignet.

Wichtige Merkmale

  • Kompaktes 1,33-Zoll-CG-Silicon-reflektives LCD mit einer aktiven Fläche von 23,808 × 23,808 mm für platzsparende Produktdesigns.

  • Flache Bauhöhe von 0,75 ± 0,1 mm und typisches Gewicht von 1,25 g zur Reduzierung der Gehäseabmessungen und des Gesamtvolumens des Systems.

  • Monochrome Farbtiefe von 1 Bit für eine einfache Darstellung von Statusanzeigen, Symbolen und grundlegenden Texten, ohne komplexe Farbwiedergabe.

  • SPI-Schnittstelle für die unkomplizierte Integration in kompakte eingebettete Systeme bei möglichst wenigen Anschlüssen.

  • Typisches Kontrastverhältnis von 25:1 für eine klare reflektive Darstellung sowie typische Anstiegs- und Abfallzeiten von 10/20 ms für reaktionsschnelle visuelle Übergänge.

  • Aktualisierungsrate von 1 Hz für Anwendungen mit sich langsam ändernden Informationen statt kontinuierlicher Bewegungsgrafiken.

  • Angegebener Betriebstemperaturbereich von -20 bis 70 °C und Lagerbereich von -30 bis 80 °C für die praxisgerechte Planung unter unterschiedlichen Umgebungsbedingungen.

Anwendungen

  • Tragbare elektronische Geräte

  • Kompakte am Handgelenk getragene Messgeräte

  • Stromsparende portable Überwachungsgeräte

  • Kleine Status- und Benutzeroberflächen-Displays

Häufig gestellte Fragen

Q1: Welche Displaytechnologie und welchen Betriebsmodus verwendet das Sharp LS013B7DH06?

A: Das Modul verwendet ein reflektives 1,33-Zoll-CG-Silicon-LCD im reflektiven Anzeigemodus und bietet eine monochrome Darstellungsoption für kompakte Geräte.

Q2: Welche Abmessungen haben die aktive Fläche und das Gehäuse des LS013B7DH06?

A: Die aktive Anzeigefläche misst 23,808 × 23,808 mm. Das Modul besitzt eine flache Gehäseabmessung von 0,75 ± 0,1 mm.

Q3: Wie kommuniziert das LS013B7DH06 mit dem Hostsystem?

A: Das Modul verwendet eine SPI-Schnittstelle und bietet damit eine praxistaugliche Anschlussoption für kompakte eingebettete Produktdesigns.

Q4: Eignet sich das LS013B7DH06 für Wearables und portable Produkte?

A: Ja. Das kompakte Format von 1,33 Zoll, die flache Gehäseabmessung von 0,75 ± 0,1 mm und das typische Gewicht von 1,25 g machen das Modul für Wearables, am Handgelenk getragene Messgeräte und andere portable Systeme gut geeignet.

Q5: Welche Farbtiefe und Aktualisierungsrate bietet das Display?

A: Das Modul bietet eine monochrome Farbtiefe von 1 Bit und eine Aktualisierungsrate von 1 Hz. Es eignet sich besonders für Statusinformationen, Symbole und andere sich langsam ändernde Inhalte.

Q6: Welche Betriebs- und Lagertemperaturbereiche sind angegeben?

A: Der angegebene Betriebstemperaturbereich liegt bei -20 bis 70 °C, der Lagerbereich bei -30 bis 80 °C.

Q7: Welches Kontrastverhältnis und welche Reaktionszeiten sind für das Modul angegeben?

A: Das typische Kontrastverhältnis beträgt 25:1. Die typischen Reaktionszeiten liegen bei 10 ms für den Anstieg und 20 ms für den Abfall.

Produktvergleich
Modell:
Größe:
Entschließung:
Helligkeit:
Kontrastverhältnis:
Betrachtungswinkel:
Lampentyp:
Signalschnittstelle:
Panel-Typ:

ls013b7dh06

128(RGB)×128 136PPI
25:1 (Typ.) (RF)
60/60/60/60 (Typ.)(CR≥2)
No B/L
5.0/5.0/3.0V (Typ.)(VDDA/VDD/VIH)
a-Si TFT-LCD, LCM
Sharp LS013B7DH01 1.26 Zoll Transflective Memory LCD Display Modul für Smartwatches

Sharp LS013B7DH01 1.26 Zoll Transflective Memory LCD Display Modul für Smartwatches

ls013b7dh01

144×168 175PPI
25:1 (Typ.) (RF)
60/60/60/60 (Typ.)(CR≥2
No B/L
SPI , 14 pins Zebra
a-Si TFT-LCD, LCM

ls013b7dh05

320×240, QVGA 90PPI
20:1 (Typ.) (RF)
60/60/60/60 (Typ.)(CR≥2)
No B/L
SPI , 10 pins FPC
a-Si TFT-LCD, LCM

ls013b7dh03

128×128 141PPI
18:1 (Typ.) (RF)
60/60/60/60 (Typ.)(CR≥2)
No B/L
3.3/3.3V (Typ.)(VDDA/VDD)
a-Si TFT-LCD, LCM
ls013b7dh06 is a a-Si TFT-LCD, LCM Display screen Product from SHARP.According to SHARP's product specification sheet,ls013b7dh06 display has a resolution of 128(RGB)×128 136PPI, Contrast Ratio is 25:1 (Typ.) (RF),Viewing Angle is 60/60/60/60 (Typ.)(CR≥2),Lamp Type is No B/L,Signal Interface is 5.0/5.0/3.0V (Typ.)(VDDA/VDD/VIH),Brightness is .Based on its characteristics, this model is recommended for application in Tablet and other products.The weight of ls013b7dh06 after packaging is 0.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
