LM340UW2-SSA1  LG Display  34 inch  lcd panel
LM340UW2-SSA1 LG Display 34 inch lcd panel
Price: €203.72
€199.19/ piece
Add to cart
LG Display LM340UW2-SSA1 34 inch 3440x1440 UWQHD 21:9 curved IPS LCD panel front view
LG Display LM340UW2-SSA1 34 inch ultrawide monitor screen LVDS interface and back cover
LG Display LM340UW2-SSA1 34 inch 3440x1440 UWQHD 21:9 curved IPS LCD panel front view
LG Display LM340UW2-SSA1 34 inch ultrawide monitor screen LVDS interface and back cover

LM340UW2-SSA1 LG Display 34 inch lcd panel

Price: €203.72
€199.19/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

LM340UW2-SSA1 LG Display 34 inch lcd panel

Product Information Product Specifications
Model:
LM340UW2-SSA1
Brand:
LG
Application:
Industrial
Resolution:
3440*1440
Brightness:
300
Contrast Ratio:
1000:1
Viewing Angle:
89/89/89/89
Lamp Type:
WLED
Signal Interface:
174 pins
Panel Type:
a-Si TFT-LCD, LCM
Frame Rate:
60
Active Area:
799.8×334.8
Outline:
819.3×363 ×19.1
Storage Temp:
-20 ~ 60 °C
Operating Temp:
0 ~ 50 °C
Support Color:
1.07B
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
165
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
6.500 KG
Overview

The LG Display LM340UW2-SSA1 is a premium 34.0-inch UltraWide TFT-LCD panel engineered for high-end gaming monitors and professional creative workstations. Featuring a stunning 3440x1440 (UWQHD) resolution and a cinematic 21:9 aspect ratio, this display delivers breathtaking detail, expansive screen real estate, and exceptional multitasking capabilities. Built with advanced AH-IPS (Advanced High-Performance In-Plane Switching) technology, it supports 1.07 billion colors (10-bit) and offers ultra-wide 178° viewing angles with flawless color accuracy. The immersive curved screen design enhances peripheral vision, making it perfect for gaming and simulations. At ZY LCD Shop, every LG Display 34-inch ultrawide panel undergoes strict testing before shipping. This UWQHD curved IPS module is the ultimate replacement screen for flagship Acer, ASUS, and Dell 34-inch monitors.

Product Features of LG Display LM340UW2-SSA1

  • UltraWide UWQHD Resolution: 34.0-inch display with a massive 3440(RGB)×1440 resolution, providing 35% more screen space than standard 1440p monitors for seamless multitasking.

  • Immersive Curved Design: Features a precise curved radius that wraps around the user's field of view, reducing eye strain and enhancing immersion in games and movies.

  • Premium AH-IPS Technology: Delivers 1.07B (10-bit) color depth and 178°/178° wide viewing angles, ensuring studio-grade color accuracy for video editing and graphic design.

  • High Contrast & Brightness: Offers a typical 1000:1 contrast ratio and 300 nits brightness, producing deep blacks and vibrant highlights.

  • Energy-Efficient WLED Backlight: Utilizes a modern White LED backlight system for uniform illumination, low power consumption, and a long operational lifespan.

Technical Specifications

LG Display LM340UW2-SSA1 Specs
ManufacturerLG Display
Model NumberLM340UW2-SSA1
Screen Size34.0 inches (Diagonal)
Resolution3440 x 1440 (UWQHD)
Aspect Ratio21:9 (UltraWide)
Panel TypeAH-IPS (In-Plane Switching)
Form FactorCurved
Color Depth1.07B (10-bit)
Brightness300 cd/m² (Typ.)
Contrast Ratio1000:1 (Typ.)
Viewing Angle89/89/89/89 (178°)
Signal InterfaceLVDS / V-by-One

Applications for the 34" UWQHD Curved IPS Panel

Thanks to its ultra-wide format, high color fidelity, and immersive curve, the LG Display LM340UW2-SSA1 is extensively used in:

  • Monitor Repair & Replacement: The perfect drop-in replacement panel for high-end 34-inch curved ultrawide monitors from brands like Acer (XR341CK), ASUS, and Dell.

  • Professional Workstations: Ideal for video editors, 3D animators, and financial traders who require massive horizontal workspace and 10-bit color accuracy.

  • High-End Gaming Displays: Provides a competitive edge and cinematic experience for immersive PC and console gaming setups.

  • Flight & Racing Simulators: The curved 21:9 format is highly sought after for building realistic racing rigs and flight simulator cockpits.

Why Choose ZY LCD Shop for Your LCD Needs?

  • 100% Tested Before Shipping: Every LG Display LM340UW2-SSA1 panel undergoes strict functional and visual quality control testing to ensure zero dead pixels and perfect backlight uniformity.

  • Competitive Pricing: As a direct supplier, ZY LCD Shop offers the most competitive prices on premium UWQHD panels without compromising original quality.

  • Safe & Fast Global Shipping: Curved screens are fragile. We use specialized custom foam and anti-static packaging to ensure safe worldwide delivery.

  • Expert Technical Support: Our display engineers are available to assist with LVDS/V-by-One pinout cross-referencing and monitor driver board compatibility.

Frequently Asked Questions (FAQ)

Can I use the LM340UW2-SSA1 to repair my Acer XR341CK or similar 34" ultrawide monitor?

Yes, the LG Display LM340UW2-SSA1 is the original OEM panel used in many flagship 34-inch 3440x1440 curved monitors, including models from Acer and ASUS. However, we always recommend opening your current monitor to verify the exact model number printed on the back of the metal chassis before ordering.

Is this a true 10-bit color depth panel?

Yes, the LM340UW2-SSA1 features AH-IPS technology capable of displaying 1.07 billion colors (10-bit). This makes it an excellent choice for professional color grading, photography, and video editing where color banding must be avoided.

How do you ship a curved 34-inch LCD panel safely?

Curved panels are highly susceptible to pressure cracks. At ZY LCD Shop, we pack the LM340UW2-SSA1 in a custom-fitted, shock-absorbent styrofoam box with reinforced cardboard corners and anti-static shielding, ensuring it arrives in perfect condition regardless of the destination.

Do you offer wholesale pricing for monitor repair shops?

Absolutely. If you are an electronics repair technician or require multiple units of the LG Display LM340UW2-SSA1 for your business, please contact us directly for customized B2B wholesale pricing.

Ready to Upgrade or Repair Your Ultrawide Monitor?

Don't settle for a cracked or flickering screen. Get your 100% tested, original LG Display 34" UWQHD Curved IPS panel today with secure packaging and fast global shipping.

Request a Quote / Contact Us Now

Product Comparison
Model:
Size:
Resolution:
Brightness:
Contrast Ratio:
Viewing Angle:
Lamp Type:
Signal Interface:
Panel Type:
LM340UW2-SSA1  LG Display  34 inch  lcd panel

LM340UW2-SSA1 LG Display 34 inch lcd panel

LM340UW2-SSA1

3440*1440
300
1000:1
89/89/89/89
WLED
174 pins
a-Si TFT-LCD, LCM
LM340UW4‑SSA1 LG 34 Inch 3440×1440 Curved IPS eDP LCD Panel

LM340UW4‑SSA1 LG 34 Inch 3440×1440 Curved IPS eDP LCD Panel

lm340uw4-ssa1

3440(RGB)×1440, 21:9
300 cd/m² (Typ.)
1000:1 (Typ.) (TM)
89/89/89/89 (Typ.)(CR≥10
4 strings × 2CN WLED, 30K hrs
eDP (8 Lanes), HBR1 (2.7G/lane) Connector
a-Si TFT-LCD, LCM
LM340UW6-SSC1 LG Display 34 inch 3440*1440 tft lcd module

LM340UW6-SSC1 LG Display 34 inch 3440*1440 tft lcd module

LM340UW6-SSC1

3440(RGB)×1440, 21:9
450 cd/m² (Typ.)
1000:1 (Typ.) (TM)
89/89/89/89 (Typ.)(CR≥10)
WLED, 30K hrs, Without Driver
eDP (8 Lanes), HBR2 (5.4G/lane), 60 pins Connector
a-Si TFT-LCD, LCM
LM340UW2-SSA1 is a a-Si TFT-LCD, LCM Display screen Product from LG.According to LG's product specification sheet,LM340UW2-SSA1 display has a resolution of 3440*1440, Contrast Ratio is 1000:1,Viewing Angle is 89/89/89/89,Lamp Type is WLED,Signal Interface is 174 pins,Brightness is 300.Based on its characteristics, this model is recommended for application in Industrial and other products.The weight of LM340UW2-SSA1 after packaging is 6.500KG.We have made every effort to minimize weighing variances; however, we cannot guarantee absolute accuracy.
