LM315WQ1-SSA1 LG Display 32  inch  tft display screen
LM315WQ1-SSA1 LG Display 32 inch tft display screen
Price: $611.27
$592.35/ piece
Add to cart
LM315WQ1-SSA1 LG Display
LM315WQ1-SSA1 LG Display
LM315WQ1-SSA1 LG Display
LM315WQ1-SSA1 LG Display

LM315WQ1-SSA1 LG Display 32 inch tft display screen

Price: $611.27
$592.35/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

LM315WQ1-SSA1 LG Display 32 inch tft display screen

Product Information Product Specifications
Model:
LM315WQ1-SSA1
Brand:
LG
Application:
Industrial
Size:
32"
Resolution:
2560*1440
Brightness:
350
Contrast Ratio:
1000:1
Viewing Angle:
89/89/89/89
Lamp Type:
WLED
Signal Interface:
60 pins
Panel Type:
a-Si TFT-LCD, LCM
Frame Rate:
165
Active Area:
697.344×392.256
Outline:
709.15×417.75×18.75
Storage Temp:
-20 ~ 60 °C
Operating Temp:
0 ~ 60 °C
Support Color:
1.07B 95% DCI-P3
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
138
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
5.500 KG
Overview

1. Product Overview

Model: LM315WQ1-SSA1

Manufacturer: LG Display

Size: 31.5 inch, Landscape, 16:9 Aspect Ratio

Native Resolution: 2560(RGB) × 1440 QHD, 93 PPI

Display Technology: IPS TFT-LCD, Normally Black Transmissive

Signal Interface: 60Pin eDP V1.4 (8 Lanes HBR2)

Backlight: Edge-lit SMD WLED, No onboard LED constant current driver; external driver required

Touch Configuration: Bare LCD panel without touch sensor

Related Versions: LM315WQ1-SSC1, LM315WQ1-SSB1 (different brightness & timing parameters)

2. Full Technical Specification Table


ClassificationStandard Parameter
Basic Display SpecDiagonal: 31.5"
Resolution: 2560 × 1440 QHD
Aspect Ratio: 16:9
Active View Area: 697.344(W) × 392.256(H) mm
Pixel Arrangement: Vertical RGB stripe
Display Mode: IPS Normally Black
Mechanical DimensionOutline: 709.15(W) × 417.75(H) × 18.75(D) mm
Surface: AG Anti-Glare polarizer (Haze 25%), 3H hard coating
Net Weight: 3.13 kg (Typ.) / 3.30 kg (Max.)
Aluminum rear housing with mounting points
Optical PerformanceTypical Brightness: 350 cd/m²
Contrast Ratio: 1000:1 (Typ., TM measurement)
Viewing Angle(CR≥10): 88°/88°/88°/88° Symmetric Wide View
Color Depth: 8-bit + FRC, 1.07B colors, 95% DCI-P3
Response Time (GtG): 4 ms typical
Native Refresh Rate: 165Hz
Electrical ParameterLogic Supply Voltage: DC 10.0V (±0.5V)
Signal Standard: eDP V1.4 8-Lane HBR2
Connector: 60Pin 0.5mm pitch eDP FPC
Typical LCD Power Consumption: ≈5.7W
Backlight SystemLight Source: Edge-type WLED (19S4P)
LED Service Life: ≥30,000 hours to half brightness
Control Signal: BL_EN + PWM continuous dimming

Environmental GradeOperating Temperature: 0 ℃ ~ +50 ℃ Commercial Grade
Storage Temperature: -20 ℃ ~ +60 ℃
Humidity: 10%~90% RH, non-condensing
CertificationRoHS, CE

3. 60Pin eDP Interface Brief Description

10V logic eDP flexible connector:
  1. Power pins: VDD 10V, multiple GND shielding pins

  2. 8-lane eDP high-speed differential data pairs

  3. HPD hot-plug detection pin

  4. LCD hardware reset pin (Active Low)

  5. Backlight control pins: BL_EN, PWM brightness adjustment

4. Core Advantages

  1. LG IPS symmetric four-direction wide viewing angle, consistent color reproduction from all viewing positions

  2. Native 165Hz high refresh rate, excellent motion performance for gaming applications

  3. Wide 95% DCI-P3 color gamut, suitable for media creation and entertainment displays

  4. AG anti-glare surface effectively reduces ambient light reflection for office environments

  5. Standard 60Pin eDP interface, compatible with mainstream monitor driver control boards

  6. Mass-produced panel widely adopted for DIY monitor assembly and aftermarket replacement

5. Typical Application Scenarios

  1. High refresh rate QHD gaming monitors

  2. Digital media entertainment display terminals

  3. Photo & video post-processing display equipment

  4. Simulation training visual display systems

  5. Monitor maintenance and spare panel replacement projects

6. Important Matching & Installation Reminders

  1. Power Requirement: LCD logic strictly requires stable DC10V input; improper voltage will cause abnormal operation

  2. Backlight Notice: No integrated WLED constant current circuit. External dedicated LED driver board must be equipped; CCFL inverters cannot be adapted

  3. Version Distinction: LM315WQ1 series suffix variants share identical outline dimensions, but optical parameters and signal timing differ; cannot be directly plug-and-play without driver adjustment

  4. Touch Customization: Standard delivery is bare LCD. Capacitive touch overlay can be bonded by OCA upon customer request

  5. FPC Cable Handling: Avoid sharp bending or excessive pulling of the 60Pin eDP cable to prevent screen flickering or no-image failure

  6. Operation Restriction: Designed for indoor commercial environment; not suitable for direct outdoor sunlight exposure without optical enhancement film

7.  FAQ

Q1: Does LM315WQ1-SSA1 integrate backlight driver circuit?

A1: No. External independent WLED constant current driver board is required.

Q2: What is the native refresh rate of this panel?

A2: 165Hz native refresh rate.

Q3: What interface does LM315WQ1-SSA1 adopt?

A3: 60Pin eDP V1.4 8-lane interface, not LVDS.

Q4: Can LM315WQ1-SSC1 replace LM315WQ1-SSA1 directly?

A4: Same mechanical outline, but brightness and timing parameters differ. Driver board parameter modification is required before replacement.

Q5: What color gamut specification does this panel support?

A5: Up to 95% DCI-P3 wide color gamut.
