AUO 14 inch screen B140XTT01.3 lcd module 1366*768 lcd display panel
AUO 14 inch screen B140XTT01.3 lcd module 1366*768 lcd display panel
Price: $65.00
$60.00/ piece
Add to cart
B140XTT01.3
B140XTT01.3
B140XTT01.3
B140XTT01.3

AUO 14 inch screen B140XTT01.3 lcd module 1366*768 lcd display panel

Price: $65.00
$60.00/ piece
Delivery:
Payment:
Calculate shipping price
Require:*
Product Model* Target price Qty *
Message
Your contact info: Additional info:
Name: *
Mr. Ms.
1. Quote with shipping freight?
Email : *
YES NO
Phone: 2. Which carrier do you perfert?
Company:
Fedex UPS DHL
TNT other
Country:*

AUO 14 inch screen B140XTT01.3 lcd module 1366*768 lcd display panel

Product Information Product Specifications
Model:
B140XTT01.3
Brand:
AUO
Application:
Industrial
Size:
14"
Resolution:
1366(RGB)×768, WXGA 112PPI
Brightness:
200 cd/m2 (Typ.)
Contrast Ratio:
500 : 1 (Typ.) (TM)
Viewing Angle:
45/45/15/35 (Typ.)(CR≥10)
Lamp Type:
WLED , 15K hours , With LED Driver
Signal Interface:
EDV-Anschluss (1 Spur)
Panel Type:
a-Si TFT-LCD, LCM
Ordering instructions
Quality:
test ok before ship it
RMA Policy:
RMA 6 month
Sample:
Paid Sample
Stock:
10
Stock Location:
China
Delivery:
WorldWide
Lead Time:
1-3 Days
Weight:
2.500 KG
Overview

B140XTT01.3 is AUO integrated on-cell capacitive touch one-piece module, widely matched for mainstream 14-inch touchscreen notebooks.

200 cd/m² standard brightness meets office, education indoor lighting environment display requirement. Classic 1366×768 WXGA resolution has abundant compatible notebook firmware and embedded driver resources.

Single-lane eDP differential signal features low power consumption and good anti-interference performance. TN panel characteristic results in limited upper viewing angle, best visual effect at lower front (6 o’clock).

CategoryParameterStandard Typical Value
Basic InfoFull ModelB140XTT01.3

ManufacturerAU Optronics (AUO)

Screen Size14.0 inch, landscape 16:9

Native Resolution1366(RGB) × 768 WXGA, 112 PPI

Panel Techa-Si TN TFT-LCD, Transmissive Normally White

Pixel ArrangementRGB vertical stripe
Optical PerformanceActive AA Area309.399(W) × 173.952(H) mm

Typical Brightness200 cd/m²

Contrast Ratio500:1 @ 25℃ ambient

Color Depth6-bit RGB, 262K colors, 45% NTSC gamut

Viewing Angle (CR≥10)L/R/U/D:45°/45°/15°/35°; Optimal viewing: 6 o’clock

Response Time (Tr+Td)8ms typical

Refresh Rate60Hz native
Mechanical SpecOverall Outline Dimension326.18(W) × 205.1(H) × 4.0(D) mm slim module

Net Weight~330g

Surface TreatmentGloss hard coat, 3H hardness
Electrical InterfaceSignal Connector40Pin 0.5mm pitch FPC single-lane eDP 1.2

Logic Supply VoltageDC 3.3V (3.0V ~ 3.6V tolerance)
Backlight SystemLight SourceEdge side WLED array

Onboard Drive CircuitBuilt-in WLED constant current IC (No external LED driver required)

WLED Rated Lifespan15,000 hours to half brightness
Touch FeatureTouch TypeEmbedded On-Cell Projected Capacitive Touch (PCAP)
Environmental RatingOperating Temperature0 ℃ ~ +50 ℃ notebook & light industrial grade

Storage Temperature-20 ℃ ~ +60 ℃

Operating Humidity10% ~ 90% RH non-condensing
Quality & StockQuality GradeNew Original A+: zero bright/dark dot, no line defect, uniform backlight

Stock StatusIn-Stock, full 4-hour aging + pixel inspection, test report attached per unit
ComplianceRoHS Lead-Free Certified, mercury-free WLED backlight

Core Key Advantages

  1. Integrated On-Cell PCAP capacitive touch, complete assembly ready for direct installation

  2. Built-in WLED constant current circuit, simplify peripheral power circuit design

  3. Slim 4.0mm thickness, lightweight design suitable for thin portable equipment

  4. Standard 40Pin single-lane eDP 1.2 interface, large amount of mature matching hardware

  5. Mature AUO mass production model, stable yield for maintenance replacement

  6. Mercury-free WLED backlight, eco-friendly

  7. Warehouse spot stock, fast delivery, each unit with complete pre-shipment test report

Typical Application Scenarios

  1. 14-inch touch notebook broken screen replacement spare assembly

  2. Portable industrial touch all-in-one embedded display terminal

  3. Education interactive learning machine, classroom touch auxiliary display

  4. Light industrial portable data collection touch terminal

  5. Replacement spare panel for AUO B140XTT01 series integrated touch TFT modules

 FAQ

Q1: Does B140XTT01.3 need external LED driver board?

A1: Not required. Built-in WLED constant current IC on PCB, only supply 3.3V VDD, BL_EN and BL_PWM signal to operate backlight normally.

Q2: Can I separate touch and LCD of this module?

A2: Not recommended. It is integrated On-Cell touch assembly, forced separation will damage LCD glass and touch layer. If you need non-touch version, select B140XTN series non-touch model.

Q3: Can eDP to LVDS converter drive this panel?

A3: Native interface is single-lane eDP 1.2; dedicated eDP-to-LVDS conversion board is required, ordinary LVDS driver cannot light it up.

Q4: What is the difference between B140XTT01.3 / B140XTT01.2 / B140XTT01.0?

A4: Same mechanical dimension and pin definition, minor touch IC version difference; most cases can be cross-replaced after touch firmware verification.

Q5: Does the module support multi-touch?

A5: Yes, embedded projected capacitive touch supports multi-touch function, requires matching touch controller and independent touch wiring.

Q6: Is the panel brand new original and in stock?

A6: Yes, all goods are 100% new original AUO A+ grade modules, sufficient inventory in warehouse, delivery within 1–3 working days after order confirmation, every unit completes pixel + touch full function test before shipment.
If you need, I can sort out the compatible notebook model list and complete 40Pin full pin mapping table for you
