Parameter description：

1. Brand：JDI

2. Size:17Inches

3. Model:TX43D22VC0CAA

4. Panel type:a-Si TFT-LCD, LCM

5. Resolution：1280(RGB)×1024, SXGA  96PPI

6. AA zone size:337.92(W)×270.336(H) mm

7. Overall dimensions:368(H)×306(V) ×19.9(D) mm

8. Brightness:1000:1 (Typ.) (TM)

9. Viewing angle:85/85/85/85 (Typ.)(CR≥10)

10. Contrast ratio:290 cd/m² (Typ.)

11. Display color:16.7M   74% NTSC

12. Optical mode:IPS-Pro, Normally Black, Transmissive

13. Response speed:10/12 (Typ.)(Tr/Td)

14. Signal interface:LVDS (2 ch, 8-bit) , 30 pins Connector

15. Light source：WLED  [3 strings] , With LED Driver

16. Touch: Without

17. Environment:Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
