Parameter description：

1. Brand：BOE

2. Size:12.1Inches

3. Model:EV121WXM-N12

4. Panel type:a-Si TFT-LCD, LCM

5. Resolution：1280(RGB)×800, WXGA  124PPI

6. AA zone size:261.12(W)×163.2(H) mm

7. Overall dimensions:277.7(W)×180.6(H)×9.2(D) mm

9. Viewing angle:85/85/85/85 (Typ.)(CR≥10)

10. Contrast ratio:1200:1 (Typ.) (TM)

11. Display color:262K/16.7M   100% sRGB

12. Optical mode:ADS, Normally Black, Transmissive

13. Response speed: 30 (Typ.)(Tr+Td)

14. Signal interface:LVDS (1 ch, 6/8-bit) 20 pins Connector

15. Light source：WLED  [12S4P] , 50K hours , With LED Driver

16. Touch: Without

17. Environment:Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
